Lexus HS I (2009-2012) head up display switch assembly Wiring diagrams
This page contains all the electrical diagrams for the component. head up display switch assembly, in which he is found in the car Lexus HS I (2009-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
head up display switch assembly wiring diagram (1 of 3)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 IG PNK WIRE
BLU WIRE
BRN WIRE
CLOCK
CLOCK ASSEMBLY (W/ NAVIGATION)
COMPUTER DATA LINES SYSTEM
DCM (TELEMATICS TRANSCEIVER) (CENTER OF DASH)
DISPLAY, NAVIGATION MODULE DISPLAY
ECU- IG 1 FUSE
ECU-ACC FUSE
ECU-IG 2 FUSE
ENGINE HOOD COURTESY SWITCH ASSEMBLY
ES TX-
GRN WIRE
GRY WIRE
HEAD UP DISPLAY SWITCH ASSEMBLY
HOT IN ON OR ACC
HOT IN ON OR START
HUD SWITCH
HYBRID VEHICLE CONTROL ECU (LEFT SIDE OF ENGINE COMPT)
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LCTY
LEFT FRONT DOOR COURTESY SWITCH (LEFT "B" PILLAR)
LEFT REAR DOOR COURTESY SWITCH (LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
MET FUSE
METER MIRROR SUB-ASSEMBLY (IF EQUIPPED)
MULTI-DISPLAY (W/O NAVIGATION)
NAVI
NAVI SWITCH
NCA WIRE
PARKING BRAKE SWITCH ASSEMBLY (PARKING BRAKE ASSEMBLY)
PNK 1 2 3 4 5 WIRE
PNK A/C+ A/CB DSE WIRE
PNK PNK 45 76 WIRE
PNK WIRE
RAD 2 FUSE
RADIO RECEIVER DISPLAY MODULE
RCTY
RED WIRE
RIGHT FRONT DOOR COURTESY SWITCH ASSEMBLY
RIGHT REAR DOOR COURTESY SWITCH ASSEMBLY
SPD GPS ANTENNA POWER MANAGEMENT CONTROL ECU (RIGHT SIDE OF DASH)
SPDI
SPDP
STEREO COMPONENT AMPLIFIER ASSEMBLY (BELOW RIGHT FRONT SEAT)
SWG
VIO WIRE
W/O NAVIGATION W/ NAVIGATION
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER RELAY ASSEMBLY (CENTER OF DASH)
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> HEAD UP DISPLAY SWITCH ASSEMBLY
head up display switch assembly wiring diagram (2 of 3)
10 11 13 14 16 COMPUTER DATA LINES SYSTEM
BBO-
BLK WIRE
BLU WIRE
BRN WIRE
GRN WIRE
GRY WIRE
HEAD UP DISPLAY SWITCH ASSEMBLY
HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) ECU- IG 2 FUSE
LT GRN WIRE
MAP LIGHT ASSEMBLY
METER MIRROR SUB-ASSEMBLY (IF EQUIPPED)
MICROPHONE AMPLIFIER
NAVI
NAVI SWITCH
NCA WIRE
PNK WIRE
RED WIRE
SOS SWITCH
VIO WIRE
W/ LEXUS ENFORM
W/O LEXUS ENFORM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Navigation circuit (4 of 6) -> HEAD UP DISPLAY SWITCH ASSEMBLY
head up display switch assembly wiring diagram (3 of 3)
10 11 13 14 16 COMPUTER DATA LINES SYSTEM
BBO-
BLK WIRE
BLU WIRE
BRN WIRE
GRN WIRE
GRY WIRE
HEAD UP DISPLAY SWITCH ASSEMBLY
HOT IN ON OR START INSTRUMENT PANEL J/B (LEFT SIDE OF DASH) ECU- IG 2 FUSE
LT GRN WIRE
MAP LIGHT ASSEMBLY
METER MIRROR SUB-ASSEMBLY (IF EQUIPPED)
MICROPHONE AMPLIFIER
NAVI
NAVI SWITCH
NCA WIRE
PNK WIRE
RED WIRE
SOS SWITCH
VIO WIRE
W/ LEXUS ENFORM
W/O LEXUS ENFORM
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, with navigation (4 of 6) -> HEAD UP DISPLAY SWITCH ASSEMBLY
