Lexus HS I (2009-2012) glove box id code light box assembly wiring diagram
This page shows the only wiring diagram for the component.glove box id code light box assembly, which is found in the car Lexus HS I (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
glove box id code light box assembly wiring diagram (1 of 1)
A/C IGNITION INVERTER COIL COMPRESSOR ASSEMBLY 1 ASSEMBLY
AIR BAG SENSOR ASSEMBLY
BATTERY VOLTAGE SENSOR
BRN WIRE
CERTIFICATION ECU VSC OFF ASSEMBLY SWITCH
DOOR CONTROL RECEIVER
DRIVING SUPPORT ECU ASSEMBLY
FROM
GLOVE BOX ID CODE LIGHT BOX ASSEMBLY
HV BATTERY JUNCTION BLOCK ASSEMBLY
HYBRID VEHICLE CONTROL ECU
HYBRID VEHICLE CONTROL ECU SHIELD
IGNITION COIL ASSEMBLY 4
IGNITION IGNITION COIL COIL ASSEMBLY 2 ASSEMBLY 3
INSTRUMENT PANEL J/B (LEFT SIDE OF DASH)
LANE RECOGNITION CAMERA SENSOR ASSEMBLY
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR DOOR W/ MOTOR LOCK ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LUGGAGE DOOR OPENING TELLTALE SWITCH LIGHT ASSEMBLY ASSEMBLY
POWER OUTLET SOCKET
POWER TILT MOTOR
RIGHT FRONT POWER SEAT SWITCH
RIGHT REAR DOOR
RIGHT REAR POWER INTER WINDOW LOCK REGULATOR SWITCH MOTOR ASSEMBLY
RIGHT RIGHT FRONT FRONT SEAT POWER INNER SEAT BELT SWITCH ASSEMBLY ASSEMBLY
SEAT BELT CONTROL ECU
SHIFT ACCELERATION LEVER PEDAL POSITION SENSOR SENSOR ASSEMBLY SHIELD SHIELD
SKID OCCUPANT CONTROL DETECTION ECU ECU ASSEMBLY SHIELD
SPIRAL CABLE SUB-ASSEMBLY
STEREO COMPONENT AMPLIFIER ASSEMBLY
TIRE PRESSURE WARNING TIRE RESET PRESSURE SWITCH WARNING ASSEMBLY ECU
WHT/BLK WIRE
WINDSHIELD WIPER RELAY ASSEMBLY
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component -> Ground distribution circuit (3 of 4) -> GLOVE BOX ID CODE LIGHT BOX ASSEMBLY
