Car Wiring Diagrams for Back door opener circuit for Lexus GX J310 (2023-2024)

BD+2 BD- BD-2 BDDN BLK WIRE BLU WIRE BZR CANN CANP COMBINATION SWITCH ASSEMBLY COMPUTER DATA LINES SYSTEM CTYO DC- DSG DSV ECU-DCC FUSE ECU-IGR 1 FUSE ECU-IGR 2 FUSE ECUB ENGINE ROOM RELAY BLOCK ASSEMBLY 1 FUL GRN WIRE HAF HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED HOT W/ IGR 2 RELAY ENERGIZED IGR KICK DOOR CONTROL SENSOR ASSEMBLY LEFT POWER BACK DOOR UNIT ASSEMBLY LIB LSBO LT BLU WIRE LT GRN WIRE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU) MSE MULTIPLEX NETWORK DOOR ECU OSE OSL OSR PAWL PBD FUSE PBDS PNK WIRE POS POWER DISTRIBUTION BOX ASSEMBLY PPL PPL/BLK WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/PNK WIRE PPL/VIO WIRE RED WIRE RIGHT END OF DASH) RIGHT POWER BACK DOOR UNIT ASSEMBLY RIGHT REAR DOOR TAN WIRE VIO WIRE WHT WIRE WHT/BLK WIRE

BACK DOOR CONTROL SWITCH BACK DOOR LOCK W/ COURTESY LIGHT SWITCH ASSEMBLY BACK DOOR OPENER SWITCH ASSEMBLY BLK WIRE BLU WIRE BRN WIRE BZR CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) CLS COMPUTER DATA LINES SYSTEM CSEL CTY DATA ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY GRN WIRE GRY WIRE LEFT POWER BACK DOOR SENSOR ASSEMBLY LT BLU WIRE LT GRN WIRE OPN OSL OSLE OSR OSRE PNK WIRE POLE POWER BACK DOOR CONTROL SWITCH 1 POWER BACK DOOR WARNING BUZZER RCO RDAM RED WIRE RIGHT POWER BACK DOOR SENSOR ASSEMBLY TAN WIRE VIO WIRE WHT WIRE WHT/BLK WIRE
