Lexus GX J310 (2023-2024) Anti-lock brakes circuit

ABS 1 FUSE ABS 2 FUSE BLK WIRE BLU WIRE CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) COMPUTER DATA LINES SYSTEM ECU- DCC 1 FUSE ECU-IGR 4 FUSE ENGINE ROOM RELAY BLOCK ASSEMBLY 2 FSW+ GRN WIRE GRY WIRE HDCS HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED IGR LEFT FRONT SPEED SENSOR LEFT PARKING BRAKE ACTUATOR ASSEMBLY LEFT REAR SPEED SENSOR LT BLU WIRE LT GRN WIRE MRL+ MRR PNK PNK SPD WIRE PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY RED WIRE RIGHT END OF DASH) RIGHT FRONT SPEED SENSOR RIGHT PARKING BRAKE ACTUATOR ASSEMBLY RIGHT REAR SPEED SENSOR SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY) STEERING SENSOR (STEERING COLUMN) VIO WIRE WHT WIRE WHT/BLK WIRE

BLK WIRE BLU WIRE BRAKE FLUID LEVEL WARNING SWITCH BRAKE PEDAL LOAD SENSING SWITCH (BRAKE PEDAL SUPPORT ASSEMBLY) COMBINATION METER ASSEMBLY COMBINATION SWITCH ASSEMBLY 4 COMPUTER DATA LINES SYSTEM FSW+ GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGR 1 RELAY ENERGIZED HSW LT BLU WIRE LT GRN WIRE METER-IGR FUSE OUT PNK WIRE POWER DISTRIBUTION BOX ASSEMBLY RADIO, DISPLAY RECEIVER ASSEMBLY RED WIRE RIGHT END OF DASH) STOP FUSE STOP LIGHT SWITCH ASSEMBLY VACUUM WARNING SWITCH ASSEMBLY VCM WHT WIRE WHT/BLK WIRE
