Lexus GX J310 (2023-2024) w/o back guide monitor system Wiring diagrams
This page contains all the electrical diagrams for the component. w/o back guide monitor system, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/o back guide monitor system (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CB+
CGND
COMPUTER DATA LINES SYSTEM
CV+
FRONT SPEAKER ASSEMBLY 5 (CENTER SIDE INSTRUMENT PANEL)
GB+
GGND
GRN WIRE
GVO+
LEFT FRONT TELEPHONE MICROPHONE ASSEMBLY (LEFT FRONT SIDE OF ROOF)
MIN
NCA WIRE
PNK WIRE
PPL/BLU WIRE
PPL/RED WIRE
PPL/WHT WIRE
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
RSW
SGND
SHIELD
SNS
SPEAKER W/ BOX ASSEMBLY
USB
USBG
USBS
USBV
VOR-
W/ TELEMATICS SYSTEM
W/O BACK GUIDE MONITOR SYSTEM
W/O TELEMATICS SYSTEM
WHT WIRE
Go to component -> Navigation circuit, 10 speaker (1 of 4) -> W/O BACK GUIDE MONITOR SYSTEM
Wiring diagram w/o back guide monitor system (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CB+
CGND
COMPUTER DATA LINES SYSTEM
CV+
FRONT SPEAKER ASSEMBLY 5 (CENTER SIDE INSTRUMENT PANEL)
GB+
GGND
GRN WIRE
GVO+
LEFT FRONT TELEPHONE MICROPHONE ASSEMBLY (LEFT FRONT SIDE OF ROOF)
MIN
NCA WIRE
PNK WIRE
PPL/BLU WIRE
PPL/RED WIRE
PPL/WHT WIRE
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
RSW
SGND
SHIELD
SNS
SPEAKER W/ BOX ASSEMBLY
USB
USBG
USBS
USBV
VOR-
W/ TELEMATICS SYSTEM
W/O BACK GUIDE MONITOR SYSTEM
W/O TELEMATICS SYSTEM
WHT WIRE
Go to component -> Radio circuit, 10 speaker (1 of 4) -> W/O BACK GUIDE MONITOR SYSTEM
