Lexus GX J310 (2023-2024) wht Wiring diagrams
This page contains all the electrical diagrams for the component. wht, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram wht (151 of 156)
ACCELERATOR PEDAL SENSOR ASSEMBLY
ACT
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
CACH
CACL
CERTIFICATION ECU (SMART KEY ECU ASSEMBLY)
COMBINATION SWITCH ASSEMBLY 4
COMPUTER DATA LINES SYSTEM
DSMS
EA (LEFT SIDE OF DASH)
ECCS
EFI 2 FUSE
EFI- IGP FUSE
EFI- MAIN 1 FUSE
EFI- MAIN 1 RELAY
ENG-IGR 2 FUSE
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
FPC
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGP 2 RELAY ENERGIZED
HOT W/ IGR 4 RELAY ENERGIZED
IGP
IGR
INSTRUMENT CLUSTER SYSTEM
IREL
IWPI
IWPO
LT BLU WIRE
LT GRN WIRE
MCMS
MPMP
NEI
NEO
ORG/ WIRE
PNK WIRE
PPMP
RED WIRE
ROTA
ROTB
SFTD
SFTU
SNWI
STARTING/CHARGING SYSTEM
STEREO COMPONENT EQUALIZER ASSEMBLY
THTW
TOW
VCPP
VIO WIRE
VPMP
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (1 of 8) -> WHT WIRE
Wiring diagram wht (152 of 156)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECU- IGP 2 FUSE
ECU-IGR 1 FUSE
ELECTRIC WATER PUMP ASSEMBLY
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
FPC
FPG
FPU
FPV
FPW
FUEL PUMP CONTROL ECU ASSEMBLY
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGP 1 RELAY ENERGIZED
HOT W/ IGR 1 RELAY ENERGIZED
LEAK DETECTION PUMP SUB-ASSEMBLY
LEFT CAM TIMING OIL CONTROL SOLENOID ASSEMBLY (BANK 2 EXHAUST SIDE)
LEFT CAM TIMING OIL CONTROL SOLENOID ASSEMBLY (BANK 2 INTAKE SIDE)
LT GRN WIRE
METER-IGR FUSE
MGND
MTRB
NWP
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RED WIRE
RIGHT CAM TIMING OIL CONTROL SOLENOID ASSEMBLY (BANK 1 EXHAUST SIDE)
RIGHT END OF DASH)
SGND
STOP FUSE
SWP
VCC
VGND
VIO WIRE
VLVB
VOUT
WHT WIRE
WHT/BLK WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (3 of 8) -> WHT WIRE
Wiring diagram wht (153 of 156)
+BM
A/F 1 FUSE
A/F 2 FUSE
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1)
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 2)
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1)
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 2)
BLK WIRE
BLU WIRE
BRN WIRE
CAN (+)
CFDS
COMPUTER DATA LINES SYSTEM
ECM (LEFT FRONT OF ENGINE COMPT)
EFI 1 FUSE
EFI-B 1 FUSE
EFI-B 2 FUSE
EFI-B 3 FUSE
EPHP
EPIM
GRN WIRE
GRY WIRE
NTP
PHPG
PIM
PNK WIRE
PPG
RED WIRE
RIGHT CAM TIMING OIL CONTROL SOLENOID ASSEMBLY (BANK 1 INTAKE SIDE)
STARTING/ CHARGING SYSTEM
THIM
TRANSMISSIONS SYSTEM
TURBO PRESSURE SENSOR 1
VACUUM SENSOR ASSEMBLY
VCPH
VCPM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (4 of 8) -> WHT WIRE
Wiring diagram wht (154 of 156)
A/F FUSE
A/F RELAY
BLK WIRE
BLU WIRE
EFC+
EFI 3 FUSE
EFI 4 FUSE
EFI- MAIN 3 FUSE
EFI- MAIN 3 RELAY
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
FLUID COUPLING ASSEMBLY
FP-
FUEL PUMP ASSEMBLY (ENGINE ROOM SIDE)
GDFC
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGN FUSE
IGT/INJ MAIN FUSE
IGT/INJ MAIN RELAY
INJ FUSE
LT BLU WIRE
NCFC
PNK WIRE
PORT FUEL INJECTOR ASSEMBLY 1
PORT FUEL INJECTOR ASSEMBLY 2
PORT FUEL INJECTOR ASSEMBLY 3
PORT FUEL INJECTOR ASSEMBLY 4
PORT FUEL INJECTOR ASSEMBLY 5
PORT FUEL INJECTOR ASSEMBLY 6
RED WIRE
VCFC
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (6 of 8) -> WHT WIRE
Wiring diagram wht (155 of 156)
BLK WIRE
BLU WIRE
BRN WIRE
DIRECT FUEL INJECTOR ASSEMBLY 1
DIRECT FUEL INJECTOR ASSEMBLY 2
DIRECT FUEL INJECTOR ASSEMBLY 3
DIRECT FUEL INJECTOR ASSEMBLY 4
DIRECT FUEL INJECTOR ASSEMBLY 5
DIRECT FUEL INJECTOR ASSEMBLY 6
E.F.I. ENGINE COOLANT TEMPERATURE SENSOR
ECF
ECM (LEFT FRONT OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE SENSOR
EPR
ETHE
EWGA
GRN WIRE
GRY WIRE
KNOCK CONTROL SENSOR (BANK 1)
KNOCK CONTROL SENSOR (BANK 2)
NCF
PNK WIRE
PTA
RED WIRE
RIGHT EFI VACUUM SENSOR ASSEMBLY
THROTTLE BODY W/ THROTTLE POSITION SENSOR ASSEMBLY
VCF
VCPF
VCPR
VCWG
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (7 of 8) -> WHT WIRE
Wiring diagram wht (156 of 156)
BLK WIRE
BLU WIRE
BRN WIRE
CAM POSITION SENSOR (BANK 1 EXHAUST SIDE)
CAM POSITION SENSOR (BANK 1 INTAKE SIDE)
CAM POSITION SENSOR (BANK 2 EXHAUST SIDE)
CAM POSITION SENSOR (BANK 2 INTAKE SIDE)
CRANK POSITION SENSOR
ENGINE OIL TEMPERATURE SENSOR (TEMPERATURE SENSOR)
EPEO
EPFL
EPTA
EX+
FGR
FUEL PRESSURE SENSOR (HIGH PRESSURE SIDE)
FUEL PRESSURE SENSOR 2 (LOW PRESSURE SIDE)
GRN WIRE
GRY WIRE
IGNITION COIL ASSEMBLY 1
IGNITION COIL ASSEMBLY 2
IGNITION COIL ASSEMBLY 3
IGNITION COIL ASSEMBLY 4
IGNITION COIL ASSEMBLY 5
IGNITION COIL ASSEMBLY 6
LEFT EFI VACUUM SENSOR ASSEMBLY
LEFT INTAKE MASS AIR FLOW METER SUB-ASSEMBLY
NE+
OIL PRESSURE SENDER GAGE ASSEMBLY
PEO
PFL
PNK WIRE
PTA
RED WIRE
RIGHT INTAKE MASS AIR FLOW METER SUB-ASSEMBLY
THAR
THEO
TOUT
TURBO PRESSURE SENSOR 2
VCC
VCCR
VCNE
VCPE
VCVG
VIO WIRE
VPTA
VVL+
VVR+
WGA
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (8 of 8) -> WHT WIRE
