Lexus GX J310 (2023-2024) voltage inverter assembly Wiring diagrams
This page contains all the electrical diagrams for the component. voltage inverter assembly, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram voltage inverter assembly (1 of 4)
ABSORBER CONTROL ECU
BRN WIRE
DIFFERENTIAL LOCK INDICATOR SWITCH
FOLD SEAT CONTROL ECU
INTERIOR ILLUMINATION LIGHT ASSEMBLY 1 (CONSOLE BOX)
LEAK DETECTION PUMP SUB-ASSEMBLY
LEFT USB CHARGER SOCKET 2
POWER BACK DOOR WARNING BUZZER
PPL/BLK WIRE
RACK, PINION POWER STEERING GEAR ASSEMBLY
REAR CENTER SEAT LAP TYPE BELT ASSEMBLY
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY SHIELD
RIGHT FOLD SEAT SWITCH ASSEMBLY
RIGHT FOLD SEAT SWITCH ASSEMBLY 1
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT REAR SEAT CUSHION HEATER ASSEMBLY 1
RIGHT REAR SEAT INNER BELT ASSEMBLY 1
RIGHT USB CHARGER SOCKET 3
TRAILER SOCKET
USB CHARGER SOCKET 2 (REAR CENTER)
VOLTAGE INVERTER ASSEMBLY
W/ CAPTAIN SEAT
W/O CAPTAIN SEAT
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 11) -> VOLTAGE INVERTER ASSEMBLY
Wiring diagram voltage inverter assembly (2 of 4)
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL WARNING SWITCH (BRAKE MASTER CYLINDER RESERVOIR ASSEMBLY)
BRN WIRE
COMPUTER DATA LINES SYSTEM
CTYL
ENGINE OIL LEVEL SENSOR
ETH (-)
GRN WIRE
GRY WIRE
LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
LEFT REAR COMBINATION LIGHT LENS, BODY
LOIL
LT BLU WIRE
ORG/ WIRE
PNK WIRE
RADIO, DISPLAY RECEIVER ASSEMBLY
RIGHT REAR COMBINATION LIGHT LENS, BODY
STEREO COMPONENT AMPLIFIER ASSEMBLY
SWG
TRN+
VACUUM WARNING SWITCH ASSEMBLY
VIO WIRE
VOLTAGE INVERTER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 3) -> VOLTAGE INVERTER ASSEMBLY
Wiring diagram voltage inverter assembly (3 of 4)
ALL DOOR LOCK RELAY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CERTIFICATION ECU (SMART KEY ECU ASSEMBLY)
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY 3
D DOOR UNLOCK RELAY
D/L FUSE
DCM FUSE
DRIVER MONITOR ECU ASSEMBLY
ECU-B 1 FUSE
ECU-B 2 FUSE
ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
FROM ENGINE ROOM RELAY BLOCK ASSEMBLY 1 (DIAGRAM 3 OF 10)
FROM IGR 2 RELAY (DIAGRAM 9 OF 10)
FUEL OPN FUSE
FUEL OPN RELAY
GRN WIRE
GRY WIRE
HAZ FUSE
ID CODE BOX (IMMOBILIZER CODE ECU)
INV 1 RELAY
L/D DOOR UNLOCK RELAY
LT BLU WIRE
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
NETWORK GATEWAY ECU
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PNK WIRE
REAR POWER OUTLET SOCKET ASSEMBLY 1
RED WIRE
RIGHT END OF DASH)
RLY
STEREO COMPONENT EQUALIZER ASSEMBLY
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
STRG LOCK FUSE
TELEMATICS TRANSCEIVER
VOLTAGE INVERTER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
Go to component -> Power distribution circuit (10 of 10) -> VOLTAGE INVERTER ASSEMBLY
Wiring diagram voltage inverter assembly (4 of 4)
BATTERY
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
CANL CANH
CERTIFICATION ECU (SMART KEY ECU ASSEMBLY)
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE ROOM J/B ASSEMBLY 1
ENGINE ROOM R/B ASSEMBLY 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
LT GRN WIRE
METER-IGR FUSE
ORG/ WIRE
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PUSH START SWITCH
RED WIRE
RIGHT END OF DASH)
ST 1 FUSE
ST RELAY
STA STAR
STARTER ASSEMBLY
VIO WIRE
VOLTAGE INVERTER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
Go to component -> Starting circuit -> VOLTAGE INVERTER ASSEMBLY
