Lexus GX J310 (2023-2024) steering wheel housing switch Wiring diagram
This page shows the only wiring diagram for the component.steering wheel housing switch, which is found in the car Lexus GX J310 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel housing switch (1 of 1)
AHB
BACKUP LAMPS CIRCUIT
BLED
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ELED
ENGINE ROOM JUNCTION BLOCK ASSEMBLY 1
GRN WIRE
GRY WIRE
HEAD
HOT AT ALL TIMES
INP STD 2 FUSE
L OFF
LEFT REAR COMBINATION LIGHT LENS, BODY
LT BLU WIRE
RED WIRE
RIGHT REAR COMBINATION LIGHT LENS, BODY
STEERING COLUMN)
STEERING SENSOR
STEERING WHEEL HOUSING SWITCH
TRN+
TURN SIGNAL SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 5) -> STEERING WHEEL HOUSING SWITCH
