Lexus GX J310 (2023-2024) side auto step controller ecu assembly Wiring diagrams
This page contains all the electrical diagrams for the component. side auto step controller ecu assembly, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
side auto step controller ecu assembly wiring diagram (1 of 3)
BLOWER MOTOR CONTROL (REAR COOLING UNIT ASSEMBLY)
BRN WIRE
CONDENSER FAN MOTOR (BLOWER ASSEMBLY W/ SHROUD)
CONTROL SWITCH ASSEMBLY
COOLING BOX AMPLIFIER
INTEGRATION CONTROL, PANEL ASSEMBLY
KA (RIGHT "B" PILLAR)
PPL
QUICK HEATER ASSEMBLY
REAR BLOWER MOTOR W/ FAN SUB- ASSEMBLY (REAR COOLING UNIT ASSEMBLY)
REFRESHING SEAT SWITCH
RIGHT END OF DASH)
RIGHT FRONT POWER SEAT SWITCH
RIGHT FRONT SEAT CUSHION HEATER ASSEMBLY
RIGHT POSITION CONTROL ECU ASSEMBLY
RIGHT POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR DOOR)
RIGHT REAR DOOR
RIGHT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT SEAT CUSHION CLIMATE BLOWER ASSEMBLY
SIDE AUTO STEP CONTROLLER ECU ASSEMBLY
SOLENOID VALVE LOWER LUMBAR (RIGHT LUMBAR SUPPORT ADJUSTER ASSEMBLY)
SOLENOID VALVE LUMBAR/REFRESH SWITCHING (RIGHT LUMBAR SUPPORT ADJUSTER ASSEMBLY)
W/ REAR AUTO AIR CONDITIONING
W/ VIBRATION SEAT
W/O REAR AUTO AIR CONDITIONING
W/O VIBRATION SEAT
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (7 of 11) -> SIDE AUTO STEP CONTROLLER ECU ASSEMBLY
side auto step controller ecu assembly wiring diagram (2 of 3)
A/C COMP FUSE
ABSORBER CONTROL ECU
AIR CONDITIONING AMPLIFIER ASSEMBLY
AVS-IGR FUSE
BLK WIRE
BLU WIRE
CDS FAN RELAY
COMBINATION SWITCH ASSEMBLY 3
CONTROL SWITCH ASSEMBLY
COOL BOX BLOWER MOTOR W/ FAN SUB-ASSEMBLY (COOLING BOX ASSEMBLY 2)
COOLING BOX ASSEMBLY
COOLING BOX MAGNET VALVE (COOLING BOX ASSEMBLY 2)
DEICER RELAY
ECU- IGP 1 FUSE
ECU- IGP 2 FUSE
ENG- IGR 1 FUSE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
FROM ENGINE ROOM RELAY BLOCK ASSEMBLY 1 (DIAGRAM 1 OF 10)
FROM ENGINE ROOM RELAY BLOCK ASSEMBLY 2 (DIAGRAM 4 OF 10)
GRN WIRE
GRY WIRE
IGP 1 RELAY
IGR 3 RELAY
NETWORK GATEWAY ECU
OPTION CONNECTOR (TIRE INFLATOR)
PNK WIRE
PPL/WHT WIRE
PTC HTR 2 RELAY
PTC- HTR 1 RELAY ENGINE ROOM RELAY BLOCK ASSEMBLY 1
RED WIRE
SEMICONDUCTOR POWER INTEGRATION ECU
SHIFT LOCK CONTROL ECU (SHIFT LOCK CONTROL UNIT ASSEMBLY)
SIDE AUTO STEP CONTROLLER ECU ASSEMBLY
SMOG VENTILATION SENSOR
STABILIZER CONTROL ECU
STB-IGR FUSE
STEREO COMPONENT EQUALIZER ASSEMBLY
STOP LIGHT SWITCH ASSEMBLY
SUB BATT RELAY
TO ENGINE ROOM RELAY BLOCK ASSEMBLY 1 (DIAGRAM 10 OF 10)
VIO WIRE
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
Go to component -> Power distribution circuit (2 of 10) -> SIDE AUTO STEP CONTROLLER ECU ASSEMBLY
side auto step controller ecu assembly wiring diagram (3 of 3)
+2 PNK -2 WIRE
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CTYL
CTYR
DPLY
ECU- IGP 2 FUSE
ECU-IGR 2 FUSE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGP 1 RELAY ENERGIZED
HOT W/ IGR 2 RELAY ENERGIZED
IGR
KA (RIGHT "B" PILLAR)
LCTY
LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
LEFT POWER LIFT STEP ASSEMBLY
LEFT REAR W/ MOTOR W/ MOTOR ASSEMBLY
MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)
OFF
PNK IGB WIRE
PNK SSR+ WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PRB FUSE
RCTY
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY
RIGHT POWER LIFT STEP ASSEMBLY
RIGHT REAR DOOR LOCK W/ MOTOR ASSEMBLY
SIDE AUTO STEP CONTROLLER ECU ASSEMBLY
SIDE AUTO STEP SWITCH ASSEMBLY
SSR+
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Retractable running boards circuit -> SIDE AUTO STEP CONTROLLER ECU ASSEMBLY
