Lexus GX J310 (2023-2024) shift position indicator Wiring diagrams
This page contains all the electrical diagrams for the component. shift position indicator, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram shift position indicator (1 of 4)
BKUP LP FUSE
BLK WIRE
BLU WIRE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGR 2 RELAY ENERGIZED
KE (RIGHT "D" PILLAR)
LEFT REAR COMBINATION LIGHT LENS, BODY
LT GRN WIRE
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PARKING ASSIST ECU
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
REV
REVD
RIGHT END OF DASH)
RIGHT REAR COMBINATION LIGHT LENS, BODY
SHIFT POSITION INDICATOR
TOW BK/UP FUSE
TOWING BK/UP RELAY
TRAILER SOCKET
TRANSMISSION CONTROL ECU ASSEMBLY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Backup lamps circuit -> SHIFT POSITION INDICATOR
Wiring diagram shift position indicator (2 of 4)
AIR CONDITIONING AMPLIFIER ASSEMBLY
BRN WIRE
CERTIFICATION ECU (SMART KEY ECU ASSEMBLY)
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY 3
COMBINATION SWITCH ASSEMBLY 4
DATA LINK CONNECTOR 3
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
HAZARD WARNING SIGNAL SWITCH ASSEMBLY
ID CODE BOX (IMMOBILIZER CODE ECU)
LEFT FRONT DOOR OUTSIDE HANDLE ASSEMBLY
METER MIRROR SUB-ASSEMBLY
NETWORK GATEWAY ECU
PARKING ASSIST ECU
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
SEAT MEMORY SWITCH
SHIFT LOCK CONTROL ECU (SHIFT LOCK CONTROL UNIT ASSEMBLY)
SHIFT POSITION INDICATOR
SIDE AUTO STEP SWITCH ASSEMBLY
THEFT WARNING INDICATOR LIGHT ASSEMBLY
TRAILER BRAKE CONTROL SWITCH
TRANSFER POSITION SWITCH
USB CHARGER SOCKET
WHT/BLK WIRE
Go to component -> Ground distribution circuit (5 of 11) -> SHIFT POSITION INDICATOR
Wiring diagram shift position indicator (3 of 4)
AUTOMATIC LIGHT CONTROL SENSOR
BLK WIRE
BLU WIRE
CLTB
CLTE
CLTS
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY 4
COMPUTER DATA LINES SYSTEM
ECU-DCC 2 FUSE
ECU-IGR 2 FUSE
ENGINE ROOM JUNCTION BLOCK ASSEMBLY 1
GRN WIRE
GRY WIRE
HEAD
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
HOT W/ IGR 2 RELAY ENERGIZED
IGR
INP STD 2 FUSE
LT GRN WIRE
MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)
METER-IGR FUSE
PANEL FUSE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RED WIRE
RIGHT END OF DASH)
SHIFT POSITION INDICATOR
TAIL RELAY
TRANSFER POSITION SWITCH
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Instrument illumination circuit (1 of 5) -> SHIFT POSITION INDICATOR
Wiring diagram shift position indicator (4 of 4)
A/BAG-IGR FUSE
AIR BAG ECU ASSEMBLY
BLK WIRE
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY 3
ECU-IGR 1 FUSE
ECU-IGR 4 FUSE
ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY
FROM ECU-IGR 3 FUSE (DIAGRAM 9 OF 10)
GRN WIRE
INTEGRATION CONTROL, PANEL ASSEMBLY
LEFT FRONT SEAT OUTER BELT ASSEMBLY
LEFT FRONT SIDE RADAR SENSOR
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY
METER-IGR FUSE
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
MULTIPLEX NETWORK DOOR ECU
NETWORK GATEWAY ECU
PNK WIRE
PPL/PNK WIRE
RADIO, DISPLAY RECEIVER ASSEMBLY
REFRESHING SEAT SWITCH
RIGHT END OF DASH)
RIGHT FRONT SEAT OUTER BELT ASSEMBLY
RIGHT FRONT SIDE RADAR SENSOR
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT POSITION CONTROL ECU ASSEMBLY
SHIFT POSITION INDICATOR
SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)
STEERING SENSOR
TRANSMISSION CONTROL SWITCH (SHIFT LOCK CONTROL UNIT ASSEMBLY)
VIO WIRE
W/ FRONT SIDE RADAR SENSOR
YEL WIRE
Go to component -> Power distribution circuit (8 of 10) -> SHIFT POSITION INDICATOR
