Lexus GX J310 (2023-2024) right step light assembly Wiring diagram
This page shows the only wiring diagram for the component.right step light assembly, which is found in the car Lexus GX J310 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right step light assembly (1 of 1)
BACK DOOR CONTROL SWITCH
BLK WIRE
BLU WIRE
FRONT DRIVER SIDE FOOTWELL LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1)
FRONT PASSENGER SIDE FOOTWELL LIGHT (INTERIOR ILLUMINATION LIGHT ASSEMBLY 1)
GRN WIRE
GRY WIRE
INTERIOR ILLUMINATION LIGHT ASSEMBLY (LEFT DOOR SCUFF PLATE ASSEMBLY)
INTERIOR ILLUMINATION LIGHT ASSEMBLY (RIGHT DOOR SCUFF PLATE ASSEMBLY)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
POWER BACK DOOR CONTROL SWITCH 1
RED WIRE
RIGHT LUGGAGE COMPARTMENT LIGHT ASSEMBLY 1
RIGHT REAR COURTESY LIGHT ASSEMBLY
RIGHT REAR DOOR
RIGHT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
RIGHT STEP LIGHT ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Courtesy lamps circuit (3 of 10) -> RIGHT STEP LIGHT ASSEMBLY
