Lexus GX J310 (2023-2024) right rear shock absorber assembly Wiring diagram
This page shows the only wiring diagram for the component.right rear shock absorber assembly, which is found in the car Lexus GX J310 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear shock absorber assembly (1 of 1)
ABSORBER CONTROL ECU
AVS-IGR FUSE
BLK WIRE
BLU WIRE
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY 4
COMPUTER DATA LINES SYSTEM
EA (LEFT SIDE OF DASH)
ECU-IGR 3 FUSE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
FAL+
FAR-
GRN WIRE
GRY WIRE
HOT W/ IGR 1 RELAY ENERGIZED
HOT W/ IGR 3 RELAY ENERGIZED
IGB
LEFT ACCELERATION SENSOR
LEFT FRONT SPEED SENSOR
LEFT REAR SHOCK ABSORBER ASSEMBLY
LT BLU WIRE
LT GRN WIRE
METER-IGR FUSE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RAL+
RAR+
RED WIRE
RIGHT ACCELERATION SENSOR
RIGHT END OF DASH)
RIGHT FRONT SPEED SENSOR
RIGHT REAR SHOCK ABSORBER ASSEMBLY
SGB
SGFL
SGFR
SGG
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Electronic air suspension circuit -> RIGHT REAR SHOCK ABSORBER ASSEMBLY
