Lexus GX J310 (2023-2024) right front seat outer belt assembly Wiring diagrams
This page contains all the electrical diagrams for the component. right front seat outer belt assembly, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front seat outer belt assembly (1 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
DBCL
DRDC
ECU-IGR 1 FUSE
HOT W/ IGR 1 RELAY ENERGIZED
LEFT "C" PILLAR)
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT FRONT SEAT OUTER BELT ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RDC
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT FRONT SEAT OUTER BELT ASSEMBLY
W/ MEMORY
W/O MEMORY
WHT WIRE
WHT/BLK WIRE
Go to component -> Passive restraints circuit -> RIGHT FRONT SEAT OUTER BELT ASSEMBLY
Wiring diagram right front seat outer belt assembly (2 of 3)
A/BAG-IGR FUSE
AIR BAG ECU ASSEMBLY
BLK WIRE
CLEARANCE WARNING ECU ASSEMBLY
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY 3
ECU-IGR 1 FUSE
ECU-IGR 4 FUSE
ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY
FROM ECU-IGR 3 FUSE (DIAGRAM 9 OF 10)
GRN WIRE
INTEGRATION CONTROL, PANEL ASSEMBLY
LEFT FRONT SEAT OUTER BELT ASSEMBLY
LEFT FRONT SIDE RADAR SENSOR
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT POSITION CONTROL ECU ASSEMBLY
METER-IGR FUSE
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
MULTIPLEX NETWORK DOOR ECU
NETWORK GATEWAY ECU
PNK WIRE
PPL/PNK WIRE
RADIO, DISPLAY RECEIVER ASSEMBLY
REFRESHING SEAT SWITCH
RIGHT END OF DASH)
RIGHT FRONT SEAT OUTER BELT ASSEMBLY
RIGHT FRONT SIDE RADAR SENSOR
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT POSITION CONTROL ECU ASSEMBLY
SHIFT POSITION INDICATOR
SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)
STEERING SENSOR
TRANSMISSION CONTROL SWITCH (SHIFT LOCK CONTROL UNIT ASSEMBLY)
VIO WIRE
W/ FRONT SIDE RADAR SENSOR
YEL WIRE
Go to component -> Power distribution circuit (8 of 10) -> RIGHT FRONT SEAT OUTER BELT ASSEMBLY
Wiring diagram right front seat outer belt assembly (3 of 3)
BLK WIRE
BRN WIRE
DRIVER'S SEAT
ECU-IGR 2 FUSE
GRN WIRE
GSW
HOT W/ IGR 2 RELAY ENERGIZED
ICL- ICL+ ICL+
L+ IG
LEFT CURTAIN SHIELD AIR BAG ASSEMBLY
LEFT FRONT AIR BAG SENSOR
LEFT FRONT SEAT AIR BAG ASSEMBLY
LEFT FRONT SEAT OUTER BELT ASSEMBLY
LEFT REAR SEAT OUTER BELT ASSEMBLY 1
MAP LIGHT ASSEMBLY
PASSIVE RESTRAINTS SYSTEM
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
R+ R-
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT AIR BAG SENSOR
RIGHT FRONT SEAT OUTER BELT ASSEMBLY
RIGHT REAR SEAT OUTER BELT ASSEMBLY 1
SEAT POSITION AIR BAG SENSOR
SFL-
SL-
SR-
TELEMATICS TRANSCEIVER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> RIGHT FRONT SEAT OUTER BELT ASSEMBLY
