Lexus GX J310 (2023-2024) rear floor side air bag sensor Wiring diagram
This page shows the only wiring diagram for the component.rear floor side air bag sensor, which is found in the car Lexus GX J310 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear floor side air bag sensor (1 of 1)
A/BAG-IGR FUSE
ACL
AIR BAG ECU ASSEMBLY
BBL+
BCL+
BDL-
BDL- BDL+
BLK WIRE
BRN WIRE
CAFH
CAFL
COMPUTER DATA LINES SYSTEM
DK+
ED (LEFT SIDE OF DASH)
EF (RIGHT CENTER OF DASH)
GNDL
GRN WIRE
GSW
HOT W/ IGR 1 RELAY ENERGIZED
ICL-
IGR
INSTRUMENT PANEL PASSENGER AIR BAG W/O DOOR ASSEMBLY
LBE- LSP- LSP+
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT SIDE AIR BAG PRESSURE SENSOR
LEFT SIDE AIR BAG SENSOR ASSEMBLY 1
LEFT SIDE AIR BAG SENSOR ASSEMBLY 2
LOWER INSTRUMENT PANEL AIR BAG ASSEMBLY 1
LSP +
MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)
P+ P-
PASSENGER SIDE KNEE AIR BAG SQUIB (LOWER INSTRUMENT PANEL AIR BAG ASSEMBLY 2)
PASSIVE RESTRAINTS SYSTEM
PK-
PL-
PLR+
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
REAR FLOOR SIDE AIR BAG SENSOR
RED WIRE
RIGHT END OF DASH)
SFL-
SL-
SPIRAL CABLE SUB-ASSEMBLY
SR-
STEERING COLUMN)
VHP-
W/ MEMORY
W/O MEMORY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> REAR FLOOR SIDE AIR BAG SENSOR
