Lexus GX J310 (2023-2024) radiator shutter assembly Wiring diagrams
This page contains all the electrical diagrams for the component. radiator shutter assembly, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram radiator shutter assembly (1 of 2)
BLK WIRE
BLU WIRE
CAN (+)
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
GRILL SHUTTER FUSE
GRN WIRE
HOT W/ EFI MAIN 3 RELAY ENERGIZED
HOT W/ IGR 1 RELAY ENERGIZED
LT GRN WIRE
METER-IGR FUSE
POWER DISTRIBUTION BOX ASSEMBLY
RADIATOR SHUTTER ASSEMBLY
RED WIRE
RIGHT END OF DASH)
W/ FRONT FOG LIGHT
WHT WIRE
WHT/BLK WIRE
Go to component -> Active bodyworks circuit -> RADIATOR SHUTTER ASSEMBLY
Wiring diagram radiator shutter assembly (2 of 2)
AIR BAG ECU ASSEMBLY
AIR CONDITIONING AMPLIFIER ASSEMBLY
BLE INDOOR DIGITAL KEY RECEIVER ASSEMBLY
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BRN WIRE
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY 2
DRIVER MONITOR ECU ASSEMBLY
EG (LEFT SIDE OF DASH)
ENGINE HOOD COURTESY SWITCH (HOOD LOCK ASSEMBLY)
GLOVE BOX LIGHT ASSEMBLY
HORN BUTTON EARTH (STEERING COLUMN ASSEMBLY)
LEFT FOG LIGHT ASSEMBLY
MOBILE WIRELESS CHARGER CRADLE ASSEMBLY
MULTIPLEX NETWORK STEERING ECU (STEERING WHEEL ASSEMBLY)
MULTIPLEX TILT, TELESCOPIC ECU
POWER OUTLET SOCKET ASSEMBLY 1
PPL
RADIATOR SHUTTER ASSEMBLY
RIGHT FOG LIGHT ASSEMBLY
RIGHT FRONT SIDE RADAR SENSOR
RIGHT HEADLIGHT ASSEMBLY
SEMICONDUCTOR POWER INTEGRATION ECU
SMOG VENTILATION SENSOR
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STEERING SENSOR
TELEMATICS TRANSCEIVER
W/ FRONT FOG LIGHT
WHT/BLK WIRE
Go to component -> Ground distribution circuit (4 of 11) -> RADIATOR SHUTTER ASSEMBLY
