Lexus GX J310 (2023-2024) pnk canh Wiring diagrams
This page contains all the electrical diagrams for the component. pnk canh, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk canh (1 of 2)
4 WHEEL DRIVE CONTROL ECU
BLK WIRE
BLU WIRE
CDL+
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DIFFERENTIAL LOCK INDICATOR SWITCH
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
GRN WIRE
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
HOT W/ IGR 4 RELAY ENERGIZED
IGR
LT GRN WIRE
METER-IGR FUSE
PNK CANH WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
REAR DIFFERENTIAL LOCK SOLENOID (REAR DIFFERENTIAL CARRIER ASSEMBLY)
RED WIRE
RIGHT END OF DASH)
SL-
SLS+
TRANSFER POSITION SWITCH
TRANSFER SHIFT ACTUATOR ASSEMBLY (LEFT REAR OF TRANSMISSION)
TRANSMISSION CONTROL ECU ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> 4wd circuit -> PNK CANH WIRE
Wiring diagram pnk canh (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ECCS
ECU-IGR 1 FUSE
ECU-IGR 2 FUSE
FORWARD RECOGNITION CAMERA
FORWARD RECOGNITION CAMERA HEATER (WINDSHIELD GLASS)
GRN WIRE
GRY WIRE
HEATER (RADIATOR GRILLE (OR FRONT PANEL) EMBLEM)
HGND
HIG
HIN
HOT W/ IGR 1 RELAY ENERGIZED
HOT W/ IGR 2 RELAY ENERGIZED
HOUT
HTR
IGB
LANE TRACING ASSIST SWITCH
LKSW
LT BLU WIRE
LT GRN WIRE
METER-IGR FUSE
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
ORG/ WIRE
PNK CANH WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RED WIRE
RIGHT END OF DASH)
SGND
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
VIO WIRE
W/ FRONT SIDE RADAR SENSOR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Lane departure warning circuit -> PNK CANH WIRE
