Lexus GX J310 (2023-2024) left rear seat back heater assembly 1 Wiring diagram
This page shows the only wiring diagram for the component.left rear seat back heater assembly 1, which is found in the car Lexus GX J310 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear seat back heater assembly 1 (1 of 1)
ECU- IGP 2 FUSE
ECU-IGR 1 FUSE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
GRN WIRE
GRY WIRE
HOT W/ IGP 1 RELAY ENERGIZED
HOT W/ IGP 2 RELAY ENERGIZED
HOT W/ IGR 1 RELAY ENERGIZED
LEFT "C" PILLAR)
LEFT REAR SEAT BACK HEATER ASSEMBLY 1
LEFT REAR SEAT CUSHION HEATER ASSEMBLY 1
LEFT SEAT HEATER CONTROL SUB-ASSEMBLY
LT BLU WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL/BLK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/PNK HTR WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/VIO WIRE
PPL/WHT WIRE
RED WIRE
RIGHT END OF DASH)
S/HTR R/L FUSE
S/HTR RR FUSE
SWR
WHT WIRE
WHT/BLK WIRE
Go to component -> Rear heated seats circuit (1 of 2) -> LEFT REAR SEAT BACK HEATER ASSEMBLY 1
