Lexus GX J310 (2023-2024) left lumbar support adjuster assembly wiring diagram
This page shows the only wiring diagram for the component.left lumbar support adjuster assembly, which is found in the car Lexus GX J310 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left lumbar support adjuster assembly wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
DRIVER'S SEAT
FDWN
FUP
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LDWN
LEFT FRONT POWER SEAT SWITCH
LEFT LUMBAR SUPPORT ADJUSTER ASSEMBLY
LIFT MOTOR (LEFT FRONT SEAT ADJUSTER ASSEMBLY)
LT BLU WIRE
LT GRN WIRE
LUP
P/SEAT D FUSE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RCLF
RCLR
RECLINING MOTOR (LEFT FRONT SEATBACK FRAME SUB-ASSEMBLY)
RED WIRE
RIGHT END OF DASH)
SLDF
SLDR
SLIDE MOTOR (LEFT FRONT SEAT ADJUSTER ASSEMBLY)
VERTICAL MOTOR (LEFT FRONT SEAT ADJUSTER ASSEMBLY)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Driver power seat circuit -> LEFT LUMBAR SUPPORT ADJUSTER ASSEMBLY
