Lexus GX J310 (2023-2024) inp std 1 fuse Wiring diagrams
This page contains all the electrical diagrams for the component. inp std 1 fuse, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram inp std 1 fuse (1 of 4)
ACAN
AUTOMATIC LIGHT CONTROL SENSOR
BLK WIRE
BLU WIRE
CANL PNK CANH WIRE
CLTB
CLTE
CLTS
COMPUTER DATA LINES SYSTEM
DMDR
DMON
DOME CUT RELAY
DOME FUSE
ECU-DCC 2 FUSE
ECU-IGR 2 FUSE
ENGINE ROOM JUNCTION BLOCK ASSEMBLY 1
FLCL
FRCL
FSPT
GRN WIRE
GRY WIRE
HEAD
HOT AT ALL TIMES
HOT W/ IGR 2 RELAY ENERGIZED
IGR
INP STD 1 FUSE
LCTY
LCYL
LT BLU WIRE
MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)
MULTI-COLOR
PNK ILE WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RCTY
RCYL
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
RIGHT FRONT SIDE COURTESY LIGHT ASSEMBLY
STPI
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Courtesy lamps circuit (1 of 10) -> INP STD 1 FUSE
Wiring diagram inp std 1 fuse (2 of 4)
ALT FUSE
BATTERY
BLK WIRE
BLK/DK GRN WIRE
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BLU WIRE
D/C CUT FUSE
ENG P/I 1 FUSE
ENG P/I 2 FUSE
ENGINE ROOM JUNCTION BLOCK ASSEMBLY 1
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
EPS-1 FUSE
GRN WIRE
GRY WIRE
HORN FUSE
HORN RELAY
HTR FUSE
IGP- MAIN 1 FUSE
IGR MAIN 3 FUSE
INP STD 1 FUSE
INP STD 2 FUSE
INP STD B FUSE
LT BLU WIRE
MULTIPLEX NETWORK DOOR ECU
OPTION CONNECTOR (TIRE INFLATOR)
PBD FUSE
PTC HTR 1 FUSE
PTC HTR 1 RELAY
PTC HTR 2 FUSE
PTC HTR 2 RELAY
RACK, PINION POWER STEERING GEAR ASSEMBLY
RADIO FUSE
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
SEMICONDUCTOR POWER INTEGRATION ECU
SUB BATT FUSE
SUB BATT RELAY
SUB R/B FUSE
TIRE INF FUSE
TO ENGINE ROOM RELAY BLOCK ASSEMBLY 1 (DIAGRAM 2 OF 10)
TO ENGINE ROOM RELAY BLOCK ASSEMBLY 2 (DIAGRAM 3 OF 10)
TO INV FUSE (DIAGRAM 3 OF 10)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 5 OF 10)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 6 OF 10)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 9 OF 10)
TOWING CONVERTER RELAY
TOWING FUSE
VIO WIRE
WASHER FUSE
WHT WIRE
WIPER FUSE
Go to component -> Power distribution circuit (1 of 10) -> INP STD 1 FUSE
Wiring diagram inp std 1 fuse (3 of 4)
AUTO
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOME CUT RELAY
DOOR F/L FUSE
DOOR R/L FUSE
DOWN
ECU-B 2 FUSE
ECU-IGR 2 FUSE
ENGINE ROOM JUNCTION BLOCK ASSEMBLY 1
FLCL
FRCL
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGR 2 RELAY ENERGIZED
IGR
INP STD 1 FUSE
LED
LEFT FRONT SIDE COURTESY LIGHT ASSEMBLY
LEFT POWER WINDOW REGULATOR MOTOR ASSEMBLY (DRIVER DOOR)
LEFT POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR DOOR)
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LT BLU WIRE
MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL
PPL/BLU WIRE
PPL/RED WIRE
RED WIRE
RIGHT END OF DASH)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Power windows circuit (1 of 2) -> INP STD 1 FUSE
Wiring diagram inp std 1 fuse (4 of 4)
AIR CONDITIONING AMPLIFIER ASSEMBLY
BLK WIRE
CANN
CANN PNK CANP WIRE
CANP
COMPUTER DATA LINES SYSTEM
CXPI
DEF
ECU-B 3 FUSE
ECU-DCC 2 FUSE
ECU-IGR 1 FUSE
ECU-IGR 2 FUSE
ENGINE ROOM JUNCTION BLOCK ASSEMBLY 1
GRN WIRE
H/T-
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
IGR
INP STD 1 FUSE
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LT BLU WIRE
MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RADIO SETTING CONDENSER
REAR WINDOW DEFOGGER WIRE (BACK DOOR GLASS)
RIGHT END OF DASH)
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
RR DEF RELAY
SIG
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Rear defogger & heated mirrors circuit -> INP STD 1 FUSE
