Lexus GX J310 (2023-2024) hot w/ efi main 3 relay energized Wiring diagram
This page shows the only wiring diagram for the component.hot w/ efi main 3 relay energized, which is found in the car Lexus GX J310 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot w/ efi main 3 relay energized (1 of 1)
BLK WIRE
BLU WIRE
CAN (+)
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
GRILL SHUTTER FUSE
GRN WIRE
HOT W/ EFI MAIN 3 RELAY ENERGIZED
HOT W/ IGR 1 RELAY ENERGIZED
LT GRN WIRE
METER-IGR FUSE
POWER DISTRIBUTION BOX ASSEMBLY
RADIATOR SHUTTER ASSEMBLY
RED WIRE
RIGHT END OF DASH)
W/ FRONT FOG LIGHT
WHT WIRE
WHT/BLK WIRE
Go to component -> Active bodyworks circuit -> HOT W/ EFI MAIN 3 RELAY ENERGIZED
