Lexus GX J310 (2023-2024) fuel opn relay Wiring diagram
This page shows the only wiring diagram for the component.fuel opn relay, which is found in the car Lexus GX J310 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel opn relay (1 of 1)
ALL DOOR LOCK RELAY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CERTIFICATION ECU (SMART KEY ECU ASSEMBLY)
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY 3
D DOOR UNLOCK RELAY
D/L FUSE
DCM FUSE
DRIVER MONITOR ECU ASSEMBLY
ECU-B 1 FUSE
ECU-B 2 FUSE
ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
FROM ENGINE ROOM RELAY BLOCK ASSEMBLY 1 (DIAGRAM 3 OF 10)
FROM IGR 2 RELAY (DIAGRAM 9 OF 10)
FUEL OPN FUSE
FUEL OPN RELAY
GRN WIRE
GRY WIRE
HAZ FUSE
ID CODE BOX (IMMOBILIZER CODE ECU)
INV 1 RELAY
L/D DOOR UNLOCK RELAY
LT BLU WIRE
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
NETWORK GATEWAY ECU
PARK/NEUTRAL POSITION SWITCH ASSEMBLY
PNK WIRE
REAR POWER OUTLET SOCKET ASSEMBLY 1
RED WIRE
RIGHT END OF DASH)
RLY
STEREO COMPONENT EQUALIZER ASSEMBLY
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
STRG LOCK FUSE
TELEMATICS TRANSCEIVER
VOLTAGE INVERTER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
Go to component -> Power distribution circuit (10 of 10) -> FUEL OPN RELAY
