Lexus GX J310 (2023-2024) ect-igp fuse Wiring diagram
This page shows the only wiring diagram for the component.ect-igp fuse, which is found in the car Lexus GX J310 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ect-igp fuse (1 of 1)
4 WHEEL DRIVE CONTROL ECU
BLK WIRE
BRAKE CONTROL RELAY W/ BRACKET
ECT-IGP FUSE
ECU- IGP 6 FUSE
EFI- IGP FUSE
ENG- IGR 4 FUSE
ENG-IGR 2 FUSE
ENG-IGR 3 FUSE
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
FROM ENGINE ROOM RELAY BLOCK ASSEMBLY 2 (DIAGRAM 3 OF 10)
FROM POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 9 OF 10)
GRN WIRE
GRY WIRE
H-LP CLN RELAY
IGP 2 RELAY
IGR 4 RELAY
LEFT HEADLIGHT ASSEMBLY
LEFT SEAT HEATER CONTROL SUB-ASSEMBLY
PNK WIRE
PPL/WHT WIRE
RED WIRE
RIGHT HEADLIGHT ASSEMBLY
RIGHT SEAT HEATER CONTROL SUB-ASSEMBLY
S/HTR R/L FUSE
S/HTR RR FUSE
TO ENGINE ROOM RELAY BLOCK ASSEMBLY 1 (DIAGRAM 2 OF 10)
TOWING- IGR FUSE
TRANSMISSION CONTROL ECU ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Power distribution circuit (4 of 10) -> ECT-IGP FUSE
