Lexus GX J310 (2023-2024) combination switch assembly 2 Wiring diagram
This page shows the only wiring diagram for the component.combination switch assembly 2, which is found in the car Lexus GX J310 (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination switch assembly 2 (1 of 1)
AIR BAG ECU ASSEMBLY
AIR CONDITIONING AMPLIFIER ASSEMBLY
BLE INDOOR DIGITAL KEY RECEIVER ASSEMBLY
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BRN WIRE
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY 2
DRIVER MONITOR ECU ASSEMBLY
EG (LEFT SIDE OF DASH)
ENGINE HOOD COURTESY SWITCH (HOOD LOCK ASSEMBLY)
GLOVE BOX LIGHT ASSEMBLY
HORN BUTTON EARTH (STEERING COLUMN ASSEMBLY)
LEFT FOG LIGHT ASSEMBLY
MOBILE WIRELESS CHARGER CRADLE ASSEMBLY
MULTIPLEX NETWORK STEERING ECU (STEERING WHEEL ASSEMBLY)
MULTIPLEX TILT, TELESCOPIC ECU
POWER OUTLET SOCKET ASSEMBLY 1
PPL
RADIATOR SHUTTER ASSEMBLY
RIGHT FOG LIGHT ASSEMBLY
RIGHT FRONT SIDE RADAR SENSOR
RIGHT HEADLIGHT ASSEMBLY
SEMICONDUCTOR POWER INTEGRATION ECU
SMOG VENTILATION SENSOR
SPIRAL CABLE SUB-ASSEMBLY
STEERING COLUMN)
STEERING SENSOR
TELEMATICS TRANSCEIVER
W/ FRONT FOG LIGHT
WHT/BLK WIRE
Go to component -> Ground distribution circuit (4 of 11) -> COMBINATION SWITCH ASSEMBLY 2
