Lexus GX J310 (2023-2024) cann pnk canp Wiring diagrams
This page contains all the electrical diagrams for the component. cann pnk canp, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cann pnk canp (1 of 3)
BDR
BDSL
BDSR
BLK WIRE
BLU WIRE
BSM
BTL
BTR
CANN
CANN PNK CANP WIRE
CANP
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CPUB
DOOR F/L FUSE
DOOR F/R FUSE
EC+
ECI+
ECU-B FUSE
ECU-DCC 2 FUSE
ECU-IGR 1 FUSE
EE (LEFT SIDE OF DASH)
GRN WIRE
GTL
GTR
H/T-
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
HSRL
HSSR
LCB+
LCV-
LCV- SHIELD SGND
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LGND
LT BLU WIRE
LT GRN WIRE
MIRRORS SYSTEM
MLP
MMRY
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PNK MM WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RED WIRE
RIGHT END OF DASH)
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
SEAT MEMORY SWITCH
SGND
SHIELD
SIG
TRN+
TRNI
VDD
VIO WIRE
VSRL
VSSR
WHT WIRE
WHT/BLK WIRE
Go to component -> Memory mirrors circuit -> CANN PNK CANP WIRE
Wiring diagram cann pnk canp (2 of 3)
BDR
BDSL
BDSR
BLK WIRE
BLU WIRE
BSM
BTL
BTR
CANN
CANN PNK CANP WIRE
CANP
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
CPUB
DOOR F/L FUSE
DOOR F/R FUSE
EC+
ECI+
ECU-B FUSE
ECU-DCC 2 FUSE
ECU-IGR 1 FUSE
ELECTROCHROMIC MIRROR CIRCUIT
GRN WIRE
GTL
GTR
H/T-
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
HSRL
HSSR
LCB+
LCV-
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LGND
LT BLU WIRE
LT GRN WIRE
MLP
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
NAVIGATION SYSTEM
NCA WIRE
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RED WIRE
RIGHT END OF DASH)
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
SGND
SHIELD
SIG
TRN+
TRNI
VDD
VIO WIRE
VSRL
VSSR
WHT WIRE
WHT/BLK WIRE
Go to component -> Power mirrors circuit -> CANN PNK CANP WIRE
Wiring diagram cann pnk canp (3 of 3)
AIR CONDITIONING AMPLIFIER ASSEMBLY
BLK WIRE
CANN
CANN PNK CANP WIRE
CANP
COMPUTER DATA LINES SYSTEM
CXPI
DEF
ECU-B 3 FUSE
ECU-DCC 2 FUSE
ECU-IGR 1 FUSE
ECU-IGR 2 FUSE
ENGINE ROOM JUNCTION BLOCK ASSEMBLY 1
GRN WIRE
H/T-
HOT AT ALL TIMES
HOT W/ IGR 1 RELAY ENERGIZED
IGR
INP STD 1 FUSE
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
LT BLU WIRE
MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RADIO SETTING CONDENSER
REAR WINDOW DEFOGGER WIRE (BACK DOOR GLASS)
RIGHT END OF DASH)
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
RR DEF RELAY
SIG
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Rear defogger & heated mirrors circuit -> CANN PNK CANP WIRE
