Lexus GX J310 (2023-2024) canl pnk canh Wiring diagrams
This page contains all the electrical diagrams for the component. canl pnk canh, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram canl pnk canh (1 of 4)
+B PNK SI WIRE
A/C COMP FUSE
A/C RR FUSE
ACT
BLK WIRE
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BLU WIRE
BRN WIRE
CANL PNK CANH WIRE
COMPUTER DATA LINES SYSTEM
CONDENSER FAN MOTOR (BLOWER ASSEMBLY W/ SHROUD)
E.F.I. ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
EWS
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGP 1 RELAY ENERGIZED
HTR FUSE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PTC HTR 1 FUSE
PTC HTR 2 FUSE
RBBU
RBUG
RBUS
REAR COOLING UNIT (COOLER WIRING HARNESS SUB-ASSEMBLY 1)
RED WIRE
SEMICONDUCTOR POWER INTEGRATION ECU
THTW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Automatic a/c circuit (4 of 4) -> CANL PNK CANH WIRE
Wiring diagram canl pnk canh (2 of 4)
ALT FUSE
BATTERY
BLK WIRE
BLK/DK GRN WIRE
BLK/WHT WIRE
CANL PNK CANH WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE ROOM J/B ASSEMBLY 1
GENERATOR ASSEMBLY
GRN WIRE
HOT W/ IGR 1 RELAY ENERGIZED
LT GRN WIRE
METER-IGR FUSE
POWER DISTRIBUTION BOX ASSEMBLY
RIGHT END OF DASH)
WHT WIRE
WHT/BLK WIRE
Go to component -> Charging circuit -> CANL PNK CANH WIRE
Wiring diagram canl pnk canh (3 of 4)
ACAN
AUTOMATIC LIGHT CONTROL SENSOR
BLK WIRE
BLU WIRE
CANL PNK CANH WIRE
CLTB
CLTE
CLTS
COMPUTER DATA LINES SYSTEM
DMDR
DMON
DOME CUT RELAY
DOME FUSE
ECU-DCC 2 FUSE
ECU-IGR 2 FUSE
ENGINE ROOM JUNCTION BLOCK ASSEMBLY 1
FLCL
FRCL
FSPT
GRN WIRE
GRY WIRE
HEAD
HOT AT ALL TIMES
HOT W/ IGR 2 RELAY ENERGIZED
IGR
INP STD 1 FUSE
LCTY
LCYL
LT BLU WIRE
MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)
MULTI-COLOR
PNK ILE WIRE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
RCTY
RCYL
RED WIRE
RIGHT END OF DASH)
RIGHT FRONT DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
RIGHT FRONT SIDE COURTESY LIGHT ASSEMBLY
STPI
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Courtesy lamps circuit (1 of 10) -> CANL PNK CANH WIRE
Wiring diagram canl pnk canh (4 of 4)
BLK WIRE
BLU WIRE
CANL PNK CANH WIRE
COMPUTER DATA LINES SYSTEM
ECU-B FUSE
ECU-IGR 2 FUSE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
FLD
FOLD SEAT CONTROL ECU
GRN WIRE
HOT AT ALL TIMES
HOT W/ IGR 2 RELAY ENERGIZED
IGR
LT GRN WIRE
MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)
PFS LH FUSE
PFS RH FUSE
PNK WIRE
POWER DISTRIBUTION BOX ASSEMBLY
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/ORG WIRE
PPL/PNK WIRE
PPL/RED WIRE
RCL+ PNK WIRE
RCL-
RECLINING OUTER MOTOR (LEFT SEAT BACK FRAME SUB-ASSEMBLY 2)
RED WIRE
RIGHT END OF DASH)
SFLD
SLIDE MOTOR (LEFT REAR SEAT LEG ASSEMBLY 2)
SLIDE MOTOR (RIGHT REAR SEAT LEG ASSEMBLY 2)
SRCL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Folding seat circuit (1 of 2) -> CANL PNK CANH WIRE
