Lexus GX J310 (2023-2024) bluetooth low energy indoor digital key receiver assembly Wiring diagrams
This page contains all the electrical diagrams for the component. bluetooth low energy indoor digital key receiver assembly, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram bluetooth low energy indoor digital key receiver assembly (1 of 2)
BLK WIRE
BLU WIRE
BLUETOOTH LOW ENERGY INDOOR DIGITAL KEY RECEIVER ASSEMBLY
BLUETOOTH LOW ENERGY LUGGAGE DIGITAL KEY RECEIVER ASSEMBLY
BRN WIRE
GRY WIRE
LEFT FRONT DOOR OUTSIDE HANDLE ASSEMBLY
LEFT REAR DOOR OUTSIDE HANDLE ASSEMBLY
LT BLU WIRE
LT GRN WIRE
PNK WIRE
RED WIRE
RIGHT FRONT DOOR OUTSIDE HANDLE ASSEMBLY
RIGHT REAR DOOR OUTSIDE HANDLE ASSEMBLY
VIO WIRE
W/O DIGITAL KEY SYSTEM
WHT WIRE
WHT/BLK WIRE
Go to component -> Forced entry circuit (4 of 6) -> BLUETOOTH LOW ENERGY INDOOR DIGITAL KEY RECEIVER ASSEMBLY
