Lexus GX J310 (2023-2024) blk/dk grn Wiring diagrams
This page contains all the electrical diagrams for the component. blk/dk grn, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram blk/dk grn (1 of 3)
ALT FUSE
BATTERY
BLK WIRE
BLK/DK GRN WIRE
BLK/WHT WIRE
CANL PNK CANH WIRE
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
ENGINE ROOM J/B ASSEMBLY 1
GENERATOR ASSEMBLY
GRN WIRE
HOT W/ IGR 1 RELAY ENERGIZED
LT GRN WIRE
METER-IGR FUSE
POWER DISTRIBUTION BOX ASSEMBLY
RIGHT END OF DASH)
WHT WIRE
WHT/BLK WIRE
Go to component -> Charging circuit -> BLK/DK GRN WIRE
Wiring diagram blk/dk grn (2 of 3)
BATTERY
BLK/DK GRN WIRE
BRN WIRE
DIGITAL KEY ECU ASSEMBLY
ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY
FORWARD RECOGNITION CAMERA
FUEL LID OPEN SENSOR (FUEL LID LOCK CONTROL CABLE SUB-ASSEMBLY)
LC (LEFT "C" PILLAR)
LD (LEFT "D" PILLAR)
LEFT CURTAIN SHIELD AIR BAG ASSEMBLY SHIELDS
LEFT FOLD SEAT SWITCH ASSEMBLY
LEFT FOLD SEAT SWITCH ASSEMBLY 1
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT INTERIOR ILLUMINATION LIGHT ASSEMBLY 1 (LEFT REAR DOOR TRIM PANEL ASSEMBLY)
LEFT REAR DOOR INSIDE HANDLE ILLUMINATION LIGHT ASSEMBLY
LEFT REAR SEAT CUSHION HEATER ASSEMBLY 1
LEFT REAR SEAT INNER BELT ASSEMBLY 1
LEFT USB CHARGER SOCKET 3
PPL
PPL/BLK WIRE
STABILIZER CONTROL ECU
STEREO COMPONENT AMPLIFIER ASSEMBLY
STEREO COMPONENT EQUALIZER ASSEMBLY
VOLTAGE INVERTER ASSEMBLY 2 (PHOTOCHROMIC PANORAMA ROOF)
W/ MEMORY
W/O MEMORY
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 11) -> BLK/DK GRN WIRE
Wiring diagram blk/dk grn (3 of 3)
ALT FUSE
BATTERY
BLK WIRE
BLK/DK GRN WIRE
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BLU WIRE
D/C CUT FUSE
ENG P/I 1 FUSE
ENG P/I 2 FUSE
ENGINE ROOM JUNCTION BLOCK ASSEMBLY 1
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
EPS-1 FUSE
GRN WIRE
GRY WIRE
HORN FUSE
HORN RELAY
HTR FUSE
IGP- MAIN 1 FUSE
IGR MAIN 3 FUSE
INP STD 1 FUSE
INP STD 2 FUSE
INP STD B FUSE
LT BLU WIRE
MULTIPLEX NETWORK DOOR ECU
OPTION CONNECTOR (TIRE INFLATOR)
PBD FUSE
PTC HTR 1 FUSE
PTC HTR 1 RELAY
PTC HTR 2 FUSE
PTC HTR 2 RELAY
RACK, PINION POWER STEERING GEAR ASSEMBLY
RADIO FUSE
RADIO, DISPLAY RECEIVER ASSEMBLY
RED WIRE
SEMICONDUCTOR POWER INTEGRATION ECU
SUB BATT FUSE
SUB BATT RELAY
SUB R/B FUSE
TIRE INF FUSE
TO ENGINE ROOM RELAY BLOCK ASSEMBLY 1 (DIAGRAM 2 OF 10)
TO ENGINE ROOM RELAY BLOCK ASSEMBLY 2 (DIAGRAM 3 OF 10)
TO INV FUSE (DIAGRAM 3 OF 10)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 5 OF 10)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 6 OF 10)
TO POWER DISTRIBUTION BOX ASSEMBLY (DIAGRAM 9 OF 10)
TOWING CONVERTER RELAY
TOWING FUSE
VIO WIRE
WASHER FUSE
WHT WIRE
WIPER FUSE
Go to component -> Power distribution circuit (1 of 10) -> BLK/DK GRN WIRE
