Lexus GX J310 (2023-2024) a/c comp fuse Wiring diagrams
This page contains all the electrical diagrams for the component. a/c comp fuse, in which he is found in the car Lexus GX J310 (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/c comp fuse (1 of 4)
+B PNK SI WIRE
A/C COMP FUSE
A/C RR FUSE
ACT
BLK WIRE
BLOWER MOTOR W/ FAN SUB-ASSEMBLY
BLU WIRE
BRN WIRE
CANL PNK CANH WIRE
COMPUTER DATA LINES SYSTEM
CONDENSER FAN MOTOR (BLOWER ASSEMBLY W/ SHROUD)
E.F.I. ENGINE COOLANT TEMPERATURE SENSOR
ENGINE COOLANT TEMPERATURE SENSOR
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
EWS
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGP 1 RELAY ENERGIZED
HTR FUSE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PTC HTR 1 FUSE
PTC HTR 2 FUSE
RBBU
RBUG
RBUS
REAR COOLING UNIT (COOLER WIRING HARNESS SUB-ASSEMBLY 1)
RED WIRE
SEMICONDUCTOR POWER INTEGRATION ECU
THTW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Automatic a/c circuit (4 of 4) -> A/C COMP FUSE
Wiring diagram a/c comp fuse (2 of 4)
A/C COMP FUSE
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECUB
ENG-IGR 3 FUSE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
ENGINE ROOM RELAY BLOCK ASSEMBLY 2
GRN WIRE
GRY WIRE
HOT W/ IGP 1 RELAY ENERGIZED
HOT W/ IGR 4 RELAY ENERGIZED
IGR
LEFT HEADLIGHT ASSEMBLY
LINL
LT BLU WIRE
LT GRN WIRE
PNK IGR WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
REAR LIGHT ASSEMBLY
RED WIRE
RIGHT HEADLIGHT ASSEMBLY
TNS
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 5) -> A/C COMP FUSE
Wiring diagram a/c comp fuse (3 of 4)
A/C COMP FUSE
ABSORBER CONTROL ECU
AIR CONDITIONING AMPLIFIER ASSEMBLY
AVS-IGR FUSE
BLK WIRE
BLU WIRE
CDS FAN RELAY
COMBINATION SWITCH ASSEMBLY 3
CONTROL SWITCH ASSEMBLY
COOL BOX BLOWER MOTOR W/ FAN SUB-ASSEMBLY (COOLING BOX ASSEMBLY 2)
COOLING BOX ASSEMBLY
COOLING BOX MAGNET VALVE (COOLING BOX ASSEMBLY 2)
DEICER RELAY
ECU- IGP 1 FUSE
ECU- IGP 2 FUSE
ENG- IGR 1 FUSE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
FROM ENGINE ROOM RELAY BLOCK ASSEMBLY 1 (DIAGRAM 1 OF 10)
FROM ENGINE ROOM RELAY BLOCK ASSEMBLY 2 (DIAGRAM 4 OF 10)
GRN WIRE
GRY WIRE
IGP 1 RELAY
IGR 3 RELAY
NETWORK GATEWAY ECU
OPTION CONNECTOR (TIRE INFLATOR)
PNK WIRE
PPL/WHT WIRE
PTC HTR 2 RELAY
PTC- HTR 1 RELAY ENGINE ROOM RELAY BLOCK ASSEMBLY 1
RED WIRE
SEMICONDUCTOR POWER INTEGRATION ECU
SHIFT LOCK CONTROL ECU (SHIFT LOCK CONTROL UNIT ASSEMBLY)
SIDE AUTO STEP CONTROLLER ECU ASSEMBLY
SMOG VENTILATION SENSOR
STABILIZER CONTROL ECU
STB-IGR FUSE
STEREO COMPONENT EQUALIZER ASSEMBLY
STOP LIGHT SWITCH ASSEMBLY
SUB BATT RELAY
TO ENGINE ROOM RELAY BLOCK ASSEMBLY 1 (DIAGRAM 10 OF 10)
VIO WIRE
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
Go to component -> Power distribution circuit (2 of 10) -> A/C COMP FUSE
Wiring diagram a/c comp fuse (4 of 4)
+SM
-WR
A/C COMP FUSE
AIR CONDITIONING SYSTEM
BLK WIRE
BLU WIRE
CXPI
ENG P/I 1 FUSE
ENG P/I 2 FUSE
ENG- IGR 1 FUSE
ENGINE ROOM RELAY BLOCK ASSEMBLY 1
EWS
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT W/ IGP 1 RELAY ENERGIZED
HOT W/ IGR 3 RELAY ENERGIZED
IGWS
PNK WIRE
RED WIRE
SEMICONDUCTOR POWER INTEGRATION ECU
VIO WIRE
WASHER FUSE
WHT WIRE
WHT/BLK WIRE
WIPER FUSE
WIPER/WASHER SYSTEM
Go to component -> Semiconductor power integration ecu circuit -> A/C COMP FUSE
