Power mirrors circuit, without automatic high beams for Lexus GX J150 (2009-2013)
Power mirrors circuit, without automatic high beams
8 10 5 IG
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
EC+
ECI+
ECU-IG 2 FUSE
GRN WIRE
INNER REAR VIEW MIRROR ASSEMBLY
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY (LEFT SIDE OF DASH)
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
MAP LIGHT ASSEMBLY
PNK ECI + WIRE
PNK WIRE
RELAY ENERGIZED
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY (CENTER OF ROOF)
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
VIO WIRE
WHT/BLK WIRE
