Lexus GX J150 (2009-2013) st air sus noise bkup lp relay relay filter relay 2 Wiring diagram
This page shows the only wiring diagram for the component.st air sus noise bkup lp relay relay filter relay 2, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram st air sus noise bkup lp relay relay filter relay 2 (1 of 1)
A/F EFI RELAY RELAY RELAY
BRAKE (LEFT SIDE ACTUATOR OF DASH) ASSEMBLY J/B 3
BRAKE ACTUATOR ASSEMBLY
CONDENSER FAN MOTOR
DRL INV RELAY RELAY
ENGINE HOOD COURTESY SWITCH
ENGINE ROOM R/B ASSEMBLY
EXCEPT HID HID TYPE TYPE
FRONT WIPER DEICER
HEADLIGHT RIGHT CLEANER HEADLIGHT CONTROL ASSEMBLY RELAY
HID TYPE
IGNITION AIR AIR COIL PUMP PUMP ASSEMBLY ASSEMBLY ASSEMBLY (BANK 1) (BANK 2)
IGNITION COIL ASSEMBLY
IGNITION IGNITION COIL COIL ASSEMBLY ASSEMBLY
J/C
LEFT FOG LIGHT ASSEMBLY
LEFT HEADLIGHT ASSEMBLY
RIGHT SMOG FOG PRESSURE VENTILATION LIGHT SWITCH 1 SENSOR ASSEMBLY
S/HTR R/R RELAY
SHORT CONNECTOR
ST AIR SUS NOISE BKUP LP RELAY RELAY FILTER RELAY 2
STOP LIGHT HEADLIGHT CONTROL SWIVEL RELAY ECU ASSEMBLY ASSEMBLY
STRG HTR RELAY
SUB FUEL BATT PMP RELAY RELAY
TOWING TAIL RELAY
TRANSFER SHIFT INLET ACTUATOR AIR ECM ASSEMBLY PUMP
WHT WIRE
WHT/BLK WIRE
WINDSHIELD BRAKE WASHER FLUID MOTOR LEVEL, PUMP WARNING ASSEMBLY SWITCH
WINDSHIELD WIPER MOTOR ASSEMBLY
WIRELESS DOOR LOCK BUZZER
Go to component -> Ground distribution circuit (1 of 5) -> ST AIR SUS NOISE BKUP LP RELAY RELAY FILTER RELAY 2
