Lexus GX J150 (2009-2013) slrl slrr rm- sgfr rm+ Wiring diagram
This page shows the only wiring diagram for the component.slrl slrr rm- sgfr rm+, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram slrl slrr rm- sgfr rm+ (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 IG
AIR SUS 2 FUSE
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA LINES SYSTEM
CONF
ENERGIZED INSTRUMENT PANEL J/B AVS FUSE ASSEMBLY (LEFT SIDE OF DASH)
ENGINE ROOM R/B ASSEMBLY (LEFT SIDE OF ENGINE COMPT)
FAL+
FAR-
FBL-
FBR-
FRONT ACCELERATION SENSOR ASSEMBLY (RIGHT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HEIGHT CONTROL COMPRESSOR MOTOR (LEFT SIDE OF LUGGAGE COMPT)
HEIGHT CONTROL EXHAUST VALVE (LEFT SIDE OF LUGGAGE COMPT)
HEIGHT CONTROL VALVE
HOT W/
J/B 4 (CENTER OF DASH)
LEFT FRONT ABSORBER CONTROL ACTUATOR (LEFT REAR OF ENGINE COMPT)
LH -
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
PNK WIRE
PNK/BLU WIRE
PNK/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RH-
RIGHT FRONT ABSORBER CONTROL ACTUATOR (RIGHT REAR OF ENGINE COMPT)
RM+
SGFL
SGL SBL
SGND
SGRR
SGV
SHB
SHG
SLRL SLRR RM- SGFR RM+
SPORT
SUSPENSION CONTROL ECU (LEFT SIDE OF DASH)
TD DNSW UPSW
VIO WIRE
VIO/GRN WIRE
VIO/RED WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Electronic air suspension circuit (1 of 2) -> SLRL SLRR RM- SGFR RM+
