Lexus GX J150 (2009-2013) side down switch Wiring diagram
This page shows the only wiring diagram for the component.side down switch, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram side down switch (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
CCW(-)
CIRCUIT
CONTROL CIRCUIT
D DOOR FUSE
D/L 2 FUSE
DOOR FUSE
DOWN
DRIVER SIDE AUTO SWITCH
DRIVER SIDE P/W
DRIVER SIDE P/W MANUAL OUTPUT CIRCUIT
DRIVER SIDE UP SWITCH
ECU-B FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B ASSEMBLY (LEFT SIDE OF ENGINE COMPT)
EPPROM
FRONT PASSENGER SIDE CONTROL SWITCH
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LED
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR SIDE CONTROL SWITCH
LIN
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU (LEFT SIDE OF DASH)
MANUAL INPUT
MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY
OUTPUT
PNK WIRE
RED WIRE
RIGHT REAR SIDE CONTROL SWITCH
SIDE DOWN SWITCH
VIO WIRE
WHT/BLK WIRE
WINDOW LOCK SWITCH
Go to component -> Power windows circuit (1 of 2) -> SIDE DOWN SWITCH
