Lexus GX J150 (2009-2013) rr washer relay Wiring diagram
This page shows the only wiring diagram for the component.rr washer relay, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rr washer relay (1 of 1)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
ENGINE ROOM R/B ASSEMBLY
ENGINE ROOM R/B RR ASSEMBLY WSH (LEFT FUSE SIDE OF ENGINE COMPT)
HOT AT ALL TIMES
INSTRUMENT MAIN BODY PANEL J/B ECU ASSEMBLY PWMR (LEFT SIDE OF DASH)
LS REAR WIPER RELAY
LT BLU WIRE
LT GRN WIRE
OFF LO
OFF LO HI
ON+WASH
REAR WIPER MOTOR ASSEMBLY (REAR OF ROOF)
REAR WIPER/ WASHER SWITCH
RED WIRE
RR WASHER RELAY
RR WIP FUSE
RR WIP WSH FUSE
VIO WIRE
WASH
WASHER FUSE
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY (RIGHT FRONT OF ENGINE COMPT)
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component -> Rear wiper/washer circuit -> RR WASHER RELAY
