Lexus GX J150 (2009-2013) right front tension reducer Wiring diagram
This page shows the only wiring diagram for the component.right front tension reducer, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front tension reducer (1 of 1)
BLK WIRE
BLU WIRE
BUCKLE SWITCH
DBCL
ECU-IG 2 FUSE
FRONT POSITION CONTROL ECU, LEFT SWITCH ASSEMBLY (DRIVER'S SEAT) DRDC
GRY WIRE
HOT IN ON OR START
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LEFT FRONT SEAT INNER BELT ASSEMBLY (UNDER DRIVER'S SEAT)
LEFT FRONT TENSION REDUCER (BASE OF LEFT "B" PILLAR)
LT BLU WIRE
PNK WIRE
RIGHT FRONT SEAT INNER BELT ASSEMBLY (UNDER FRONT PASSENGER'S SEAT)
RIGHT FRONT TENSION REDUCER
SWITCH BUCKLE
WHT/BLK WIRE
Go to component -> Passive restraints circuit -> RIGHT FRONT TENSION REDUCER
