Lexus GX J150 (2009-2013) relay energized Wiring diagrams
This page contains all the electrical diagrams for the component. relay energized, in which he is found in the car Lexus GX J150 (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
relay energized wiring diagram (21 of 25)
+BM
1 RELAY ENERGIZED
12 22 23 EC +B
24 9 8 BATT MREL
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
ECM (RIGHT SIDE OF DASH)
ECU- IG 1 FUSE
ELECTRONICALLY CONTROLLED TRANSMISSION SOLENOID (TRANSMISSION ASSEMBLY)
ENGINE ROOM R/B ASSEMBLY (LEFT SIDE OF ENGINE COMPT)
ETA M-
ETCS FUSE
FUSE
GAUGE FUSE
GRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACC RELAY ENERGIZED
IGN FUSE
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
PNK/BLU WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RELAY ENERGIZED
SFTU SFTD VPA EPA VCPA
SLT- SLT+ SLU+ SLU-
STOP FUSE
THROTTLE BODY ASSEMBLY (TOP FRONT OF ENGINE)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> A/t circuit (1 of 2) -> RELAY ENERGIZED
relay energized wiring diagram (22 of 25)
1 2 3 4 5 6 7 8 9 10 RCL+ +B
BLK WIRE
BLK/WHT WIRE
BLU WIRE
ECU- IG 1
FLD- FLD+
FOLD
FOLD SEAT SWITCH ASSEMBLY 2 (REAR SEAT)
FOLDING MOTOR
FUSE
GRN WIRE
GRY WIRE
HALL IC SENSOR
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LT BLU WIRE
LT GRN WIRE
PARK/NEUTRAL POSITION SWITCH
PNK RCLF RCLR WIRE
PNK WIRE
RCL-
RECLINING MOTOR
RED WIRE
RELAY ENERGIZED
RIGHT FOLD SEAT CONTROL ECU (UNDER RIGHT REAR SEAT)
RIGHT REAR POWER SEAT SWITCH
RIGHT SEAT BACK FRAME SUB-ASSEMBLY 3
RIGHT SEAT CUSHION FRAME SUB-ASSEMBLY 2
RTRN
RTRN FOLD
SFLD SRCL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Rear folding seat circuit (2 of 2) -> RELAY ENERGIZED
relay energized wiring diagram (23 of 25)
A/C CONTROL ASSEMBLY 2
BLK WIRE
BLU WIRE
COM
ECU-IG 2 FUSE
ENGINE ROOM R/B 3 (RIGHT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B ASSEMBLY (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B IG 1 FUSE ASSEMBLY (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
J/B 4
J/B 4 (CENTER OF DASH)
LEFT REAR SEAT HEATER ASSEMBLY (LEFT SIDE OF REAR SEAT)
PNK RLY WIRE
PNK WIRE
PWR
REAR SEAT HEATER SWITCH
RED WIRE
RELAY ENERGIZED
RIGHT REAR SEAT HEATER ASSEMBLY (RIGHT SIDE OF REAR SEAT)
RLY
RR S/HTR FUSE
S/HTR R/R RELAY
SEAT BACK)
SEAT CUSHION)
SEAT HEATER CONTROL
SWL
THERMISTOR
THL
THR+
VIO WIRE
WHT/BLK WIRE
Go to component -> Rear heated seats circuit -> RELAY ENERGIZED
relay energized wiring diagram (24 of 25)
31 32 CANL CANH
BLU WIRE
COMPUTER DATA LINES SYSTEM
DIODE (SHIFT POSITION) (CENTER OF DASH)
ECM (RIGHT SIDE OF DASH)
ECU- IG 1 FUSE
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES ENGINE ROOM R/B ASSEMBLY STOP FUSE (LEFT SIDE OF ENGINE COMPT)
HOT W/ ACC RELAY ENERGIZED
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
P DETECTION SWITCH
PARK/NEUTRAL POSITION SWITCH
PNK WIRE
POWER MANAGEMENT CONTROL ECU (CENTER OF DASH)
RED WIRE
RELAY ENERGIZED
SHIFT LOCK CONTROL ECU SUB ASSEMBLY (CENTER CONSOLE)
SLS+
SLS+ SHIFT LOCK SOLENOID
STOP LIGHT SWITCH ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Shift interlock circuit -> RELAY ENERGIZED
relay energized wiring diagram (25 of 25)
3 2 IGE
ENGINE ROOM R/B ASSEMBLY (LEFT SIDE OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGN ASSEMBLY FUSE (LEFT SIDE OF DASH)
INSTRUMENT PANEL J/B
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LIN
LT BLU WIRE
POWER MANAGEMENT CONTROL ECU
RELAY ENERGIZED
SL/R
SLP
STEERING LOCK ACTUATOR ASSEMBLY
STRG LOCK FUSE
WHT WIRE
WHT/BLK WIRE
Go to component -> Steering column circuit -> RELAY ENERGIZED
