Lexus GX J150 (2009-2013) power point socket assembly Wiring diagrams
This page contains all the electrical diagrams for the component. power point socket assembly, in which he is found in the car Lexus GX J150 (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram power point socket assembly (1 of 2)
D DR UNLOCK RELAY
DOOR CONTROL RECEIVER
DOOR LOCK RELAY
DR UNLOCK RELAY
FOLD SEAT SWITCH ASSEMBLY
FROM
FUEL LID MOTOR ASSEMBLY
G/H OPNER RELAY RELAY
HEIGHT CONTROL EXHAUST VALVE
HEIGHT HEIGHT CONTROL CONTROL COMPRESSOR VALVE MOTOR
INNER REAR VIEW MIRROR ASSEMBLY
J/C
LEFT BACKUP LIGHT ASSEMBLY
LEFT FOLD SEAT CONTROL ECU
LEFT FRONT SIDE STEP LIGHT
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR POWER SEAT SWITCH
LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LEFT REAR SEAT HEATER ASSEMBLY
LEFT REAR SIDE STEP LIGHT
LEFT SEAT BACK CLIMATE CONTROL BLOWER
LEFT SEAT CUSHION FRAME SUB- ASSEMBLY
MAIN BODY ECU
NCA WIRE
POWER POINT SOCKET ASSEMBLY
RELAY
RIGHT BACKUP LIGHT ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
SHIELD
SLIDING ROOF MAP LIGHT CONTROL ASSEMBLY ECU
STEERING WHEEL HEATER CONTROL ASSEMBLY
TOWING BRAKE CONTROLLER
TRAILER SOCKET
W/O AUTOMATIC HIGH BEAM SYSTEM
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component -> Ground distribution circuit (5 of 5) -> POWER POINT SOCKET ASSEMBLY
Wiring diagram power point socket assembly (2 of 2)
A/C FUSE
AIR CONDITIONING SYSTEM
BK/UP RELAY
BLK WIRE
BLK/WHT WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
D DOOR FUSE
D/L 2 FUSE
D/L SOURCE RELAY
DEFOGGER SYSTEM
DEFOGGER, POWER WINDOWS, MEMORY SYSTEMS
DOOR FUSE
ECU- IG 1 FUSE
ECU-IG 2 FUSE
ENGINE ROOM R/B ASSEMBLY
FL P/SEAT FUSE
FR FOG FUSE
FR FOG RELAY
FROM ENGINE ROOM J/B (DIAGRAM 1 OF 3)
FROM J/B 4 (DIAGRAM 1 OF 3)
FROM OBD FUSE (DIAGRAM 2 OF 3)
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
IG 1 FUSE FR S/HTR FUSE
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
J/C
LT GRN WIRE
MAIN BODY ECU
MEMORY SYSTEMS
MIRRORS SYSTEM
OBD FUSE
P DOOR FUSE
P/OUTLET FUSE FUSE
PASSIVE RESTRAINT SYSTEM
PNK WIRE
POWER POINT SOCKET ASSEMBLY
POWER TOPS SYSTEM
POWER TOPS, MIRRORS, NAVIGATION GARAGE DOOR OPENER, WIPER/WASHER SYSTEMS
POWER WINDOWS SYSTEM
POWER WINDOWS, MEMORY SYSTEMS
PSB FUSE
R/L DOOR FUSE
R/R DOOR FUSE
RED WIRE
RELAY
S/ROOF TI&TE FUSE FUSE
SEATS SYSTEM
SOUND, NAVIGATION, INSTRUMENT CLUSTER SYSTEMS
SUPPLEMENTAL RESTRAINTS SYSTEM
TAIL RELAY
TO IG 2 RELAY (DIAGRAM 3 OF 3)
TO POWER MANAGEMENT CONTROL ECU (DIAGRAM 3 OF 3)
TO TAIL RELAY (DIAGRAM 2 OF 3)
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
WHT WIRE
Go to component -> Power distribution circuit (2 of 3) -> POWER POINT SOCKET ASSEMBLY
