Lexus GX J150 (2009-2013) pnk eci + Wiring diagrams
This page contains all the electrical diagrams for the component. pnk eci +, in which he is found in the car Lexus GX J150 (2009-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram pnk eci + (1 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 IG
8 10 5 IG
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
EC+
EC+ EC-
ECI+
ECU-IG 2 FUSE
GRN WIRE
INNER REAR VIEW MIRROR ASSEMBLY
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY (LEFT SIDE OF DASH)
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
MAP LIGHT ASSEMBLY
PNK ECI + WIRE
PNK WIRE
RELAY ENERGIZED
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY (CENTER OF ROOF)
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
VIO WIRE
WHT/BLK WIRE
Go to component -> Power mirrors circuit, with automatic high beams -> PNK ECI + WIRE
Wiring diagram pnk eci + (2 of 2)
8 10 5 IG
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
EC+
ECI+
ECU-IG 2 FUSE
GRN WIRE
INNER REAR VIEW MIRROR ASSEMBLY
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LEFT OUTER MIRROR CONTROL ECU ASSEMBLY (LEFT SIDE OF DASH)
LEFT OUTER REAR VIEW MIRROR ASSEMBLY
MAP LIGHT ASSEMBLY
PNK ECI + WIRE
PNK WIRE
RELAY ENERGIZED
RIGHT OUTER MIRROR CONTROL ECU ASSEMBLY (CENTER OF ROOF)
RIGHT OUTER REAR VIEW MIRROR ASSEMBLY
VIO WIRE
WHT/BLK WIRE
Go to component -> Power mirrors circuit, without automatic high beams -> PNK ECI + WIRE
