Lexus GX J150 (2009-2013) lumbar right front power seat switch assembly Wiring diagram
This page shows the only wiring diagram for the component.lumbar right front power seat switch assembly, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lumbar right front power seat switch assembly (1 of 1)
BLK WIRE
BLU WIRE
DOWN UP
FRONT
FRONT DOWN
FRONT VERTICAL
FRONT VERTICAL MOTOR
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
LEFT SEPARATE TYPE FRONT SEAT BACK ASSEMBLY
LIFTER
LIFTER MOTOR
LT BLU WIRE
LT GRN WIRE
LUMBAR RIGHT FRONT POWER SEAT SWITCH ASSEMBLY
P/SEAT (FR) FUSE
PNK WIRE
REAR
REAR UP
RECLINING
RECLINING MOTOR
RED WIRE
RIGHT FRONT POWER SEAT SWITCH
RIGHT SEPARATE TYPE FRONT SEAT BACK ASSEMBLY
RIGHT SEPARATE TYPE FRONT SEAT CUSHION SPRING ASSEMBLY
SLIDE
SLIDE MOTOR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Passenger power seat circuit -> LUMBAR RIGHT FRONT POWER SEAT SWITCH ASSEMBLY
