Lexus GX J150 (2009-2013) left seat back frame sub-assembly 3 Wiring diagram
This page shows the only wiring diagram for the component.left seat back frame sub-assembly 3, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left seat back frame sub-assembly 3 (1 of 1)
1 2 3 4 5 6 7 8 9 10 RCL+ +B
BLK WIRE
BLK/WHT WIRE
BLU WIRE
ECU-B FUSE
ENGINE ROOM R/B ASSEMBLY
FLD- FLD+
FLDL
FOLD SEAT SWITCH ASSEMBLY 1
GRN WIRE
GRY WIRE
HALL IC SENSOR
HOT AT ALL TIMES
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LEFT FOLD SEAT CONTROL ECU (UNDER LEFT REAR SEAT)
LEFT REAR POWER SEAT SWITCH
LEFT SEAT BACK FRAME SUB-ASSEMBLY 3
LEFT SEAT CUSHION FRAME SUB-ASSEMBLY 2
LH FOLD SEAT FUSE
LT BLU WIRE
LT GRN WIRE
MOTOR FOLDING
MOTOR RECLINING
NCA WIRE
PNK RCLF RCLR WIRE
PNK WIRE
RCL-
RED WIRE
RELAY ENERGIZED ECU-IG 2 FUSE
RH (LEFT SIDE OF FOLD ENGINE COMPT) SEAT FUSE
RTNL RTNR FLDR
RTRN FOLD
SFLD SRCL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Rear folding seat circuit (1 of 2) -> LEFT SEAT BACK FRAME SUB-ASSEMBLY 3
