Lexus GX J150 (2009-2013) headlight dimmer switch assembly 1 2 3 4 5 6 hdlo Wiring diagram
This page shows the only wiring diagram for the component.headlight dimmer switch assembly 1 2 3 4 5 6 hdlo, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlight dimmer switch assembly 1 2 3 4 5 6 hdlo (1 of 1)
BLK WIRE
BLU WIRE
DRL OFF (OR) OFF
ECU-B FUSE
ENERGIZED ECU IG 2 FUSE
ENGINE ROOM R/B ASSEMBLY
EW WF
FRONT WASHER SWITCH
FRWA PB
GRN WIRE
HEAD AUTO
HEADLIGHT CLEANER CONTROL RELAY (BEHIND LEFT HEADLIGHT)
HEADLIGHT CLEANER MOTOR, PUMP ASSEMBLY (RIGHT FRONT OF ENGINE COMPT)
HEADLIGHT CLEANER SWITCH ASSEMBLY
HEADLIGHT DIMMER SWITCH ASSEMBLY 1 2 3 4 5 6 HDLO
HOT AT ALL TIMES
HOT W/
HRLY HDLO BECU HEAD
J/B 3 (LEFT SIDE OF DASH)
J/C
LIGHT CONTROL SWITCH
ORG/ WIRE
TAIL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
Go to component -> Headlamp washer circuit -> HEADLIGHT DIMMER SWITCH ASSEMBLY 1 2 3 4 5 6 HDLO
