Lexus GX J150 (2009-2013) driving support ecu assembly Wiring diagram
This page shows the only wiring diagram for the component.driving support ecu assembly, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driving support ecu assembly (1 of 1)
AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) SHIELD
AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1) SHIELD
BACK WINDOW LOCK ASSEMBLY
BLK WIRE
BRN WIRE
CANISTER PUMP MODULE
CENTER STOP LIGHT ASSEMBLY
COMBINATION METER ASSEMBLY
DATA LINK CONNECTOR 3
DRIVER AIR INJECTION CONTROL
DRIVING SUPPORT ECU ASSEMBLY
GLASS BACK HATCH DOOR OPENER LOCK SWITCH ASSEMBLY ASSEMBLY
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
KNOCK CONTROL SENSOR (BANK 1 SENSOR 1) SHIELD
KNOCK CONTROL SENSOR (BANK 1 SENSOR 2) SHIELD
KNOCK CONTROL SENSOR (BANK 2 SENSOR 1)
KNOCK CONTROL SENSOR (BANK 2 SENSOR 2) SHIELD
LUGGAGE ELECTRICAL KEY SWITCH
MILLIMETER WAVE RADAR SENSOR ASSEMBLY
OXYGEN SENSOR (BANK 1 SENSOR 2) SHIELD
OXYGEN SENSOR (BANK 2 SENSOR 2) SHIELD
REAR BLOWER W/ FAN MOTOR SUB- ASSEMBLY
REAR BLOWER W/ FAN VOLTAGE MOTOR INVERTER SUB- ASSEMBLY ASSEMBLY
REAR WINDOW DEFOGGER (BLACK DOOR GLASS)
REAR WIPER MOTOR ASSEMBLY
RIGHT FOLD SEAT CONTROL ECU
RIGHT FRONT POWER SEAT SWITCH
RIGHT FRONT SIDE STEP LIGHT
RIGHT REAR DOOR LOCK ASSEMBLY
RIGHT REAR POWER SIDE OUTLET STEP SOCKET LIGHT
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR SEAT HEATER ASSEMBLY
RIGHT SEAT BACK CLIMATE CONTROL BLOWER
SHIELD
SPIRAL CABLE SUB-ASSEMBLY
TIRE PRESSURE WARNING ECU
VOLTAGE INVERTER ASSEMBLY
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 5) -> DRIVING SUPPORT ECU ASSEMBLY
