Lexus GX J150 (2009-2013) clearance sonar ind power ig+ supply circuit 39 40 21 canl canh Wiring diagram
This page shows the only wiring diagram for the component.clearance sonar ind power ig+ supply circuit 39 40 21 canl canh, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram clearance sonar ind power ig+ supply circuit 39 40 21 canl canh (1 of 1)
16 7 12 3 4 GND IG
3 5 1 4 2 6 SI EI BI SO BO EO
34 33 CANP CANN
5 1 3 4 2 6 EI BI SI SO BO EO
5 1 3 EI BI SI
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BOF
BRN WIRE
CLEARANCE SONAR IND POWER IG+ SUPPLY CIRCUIT 39 40 21 CANL CANH
CLEARANCE WARNING BUZZER 1 (LEFT CENTER OF DASH)
CLEARANCE WARNING ECU ASSEMBLY (RIGHT SIDE OF DASH)
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DIODE (SHIFT POSITION) (CENTER OF DASH)
DOWN
DRIVING SUPPORT SWITCH CONTROL ECU (CENTER OF DASH)
ECM (RIGHT SIDE OF DASH)
ECU-IG 2 FUSE
ENTER
FUSE
GAUGE FUSE J/B ASSEMBLY (LEFT SIDE OF DASH)
GRN WIRE
GRY WIRE
HOT IN ON OR ACC
HOT IN ON OR START
INSTRUMENT PANEL
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LEFT FRONT CENTER ULTRASONIC SENSOR 1 (FRONT LEFT OF BUMPER)
LEFT FRONT ULTRASONIC SENSOR 1 (LEFT SIDE OF BUMPER)
LEFT REAR CENTER ULTRASONIC SENSOR 1
LEFT REAR ULTRASONIC SENSOR 1
LT BLU WIRE
LT GRN WIRE
MENU
MICRO COMPUTER
PARK/NEUTRAL POSITION SWITCH
PNK BOR WIRE
PNK PNK WIRE
PNK WIRE
PNK/BLU WIRE
RED WIRE
RED/BLU WIRE
RIGHT FRONT CENTER ULTRASONIC SENSOR 1 (RIGHT FRONT CENTER OF BUMPER)
RIGHT FRONT ULTRASONIC SENSOR 1 (RIGHT SIDE OF FRONT BUMPER)
RIGHT REAR CENTER ULTRASONIC SENSOR 1
RIGHT REAR ULTRASONIC SENSOR 1
RIGHT STEERING PAD SWITCH
SOF BBZ EF CSSW
SOR
SPIRAL CABLE SUB-ASSEMBLY
STEERING PAD SWITCH ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Rear sonar circuit -> CLEARANCE SONAR IND POWER IG+ SUPPLY CIRCUIT 39 40 21 CANL CANH
