Lexus GX J150 (2009-2013) brake actuator assembly (left rear of Wiring diagram
This page shows the only wiring diagram for the component.brake actuator assembly (left rear of, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake actuator assembly (left rear of (1 of 1)
27 11 25 EXI CANH CANL
4 WHEEL DRIVE CONTROL ECU (RIGHT SIDE OF DASH)
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY (LEFT REAR OF
BRN WIRE
CDL+
CENTER DIFFERENTIAL LOCK IND
CENTER DIFFERENTIAL LOCK SWITCH (CENTER OF DASH)
CIRCUIT SUPPLY POWER
COMBINATION METER ASSEMBLY
COMBINATION SWITCH ASSEMBLY
COMPUTER DATA DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM
ECM (RIGHT SIDE OF DASH)
ENGINE COMPT)
FUSE
GAUGE FUSE
GRN WIRE
GRY WIRE
HOT IN ON OR START
IG GND
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
J/B 4 (CENTER OF DASH)
LT GRN WIRE
MICRO COMPUTER
PNK WIRE
RED WIRE
RED/BLU WIRE
RLP DL
TRANSFER SHIFT ACTUATOR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
Go to component -> 4wd circuit -> BRAKE ACTUATOR ASSEMBLY (LEFT REAR OF
