Lexus GX J150 (2009-2013) 4 5 pnk auto gnd Wiring diagram
This page shows the only wiring diagram for the component.4 5 pnk auto gnd, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 4 5 pnk auto gnd (1 of 1)
4 5 PNK AUTO GND WIRE
AUTO
AUTO DOWN UP 4 7 10 PNK WIRE
AUTO GND 4 5 PNK WIRE
AUTO PNK WIRE
BLK WIRE
BLU WIRE
CCW(-)
CIRCUIT INPUT
CIRCUIT OUTPUT
DOOR LOCKS SYSTEM
DOWN
EEPROM
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INPUT CIRCUIT
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
LED
LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LIN
LOCK
LT BLU WIRE
OUTPUT I/F CIRCUIT
P DOOR FUSE
PNK WIRE
R/L DOOR FUSE
R/R DOOR FUSE
RED WIRE
RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Power windows circuit (2 of 2) -> 4 5 PNK AUTO GND WIRE
