Lexus GX J150 (2009-2013) 32 31 14 13 ig altb trly ffgo wiring diagram
This page shows the only wiring diagram for the component.32 31 14 13 ig altb trly ffgo, which is found in the car Lexus GX J150 (2009-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
32 31 14 13 ig altb trly ffgo wiring diagram (1 of 1)
1 19 6 GCTY BCTY RCTY
15 13 14 5 8 29 30 28 27 PNK DIM CANL CANH HU HF HEAD TAIL WIRE
30 15 25 BECU HRLY DRL
32 31 14 13 IG ALTB TRLY FFGO
4 2 FRCY FLCY
ALT FUSE
AUTO TAIL
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
D/L 2 FUSE
DIMMER SWITCH
ECU-IG 2 FUSE
ENGINE ROOM J/B ASSEMBLY (LEFT SIDE OF ENGINE COMPT)
FR FOG FUSE
FR FOG RELAY
GAUGE FUSE
GRN WIRE
GRY WIRE
HEAD TAIL FRONT AUTO OFF OFF (CANADA) DRL OFF (USA) FOG LIGHT SWITCH
HOT AT ALL TIMES
HOT W/ IG 1 RELAY ENERGIZED
INSTRUMENT PANEL J/B ASSEMBLY (LEFT SIDE OF DASH)
J/B 3 (LEFT SIDE OF DASH)
LCTY
LEFT FOG LIGHT ASSEMBLY
LIGHT CONTROL SWITCH HEADLIGHT DIMMER SWITCH ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU
PNK WIRE
RED WIRE
RIGHT FOG LIGHT ASSEMBLY
TAIL FUSE
TAIL RELAY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Headlamps & fog lamps circuit (1 of 2) -> 32 31 14 13 IG ALTB TRLY FFGO
