Front wiper/washer circuit, with rain sensor for Lexus GX J120 (2002-2009)

ACC CUT RELAY AUTO AUTO OFF BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE COMBINATION SWITCH CONNECTOR 2 (LEFT SIDE OF ENGINE COMPT) DIODE (BACK-UP LIGHT) (BEHIND RIGHT SIDE OF DASH) DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) EB (ON LEFT FRONT INNER FENDER) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) FR WIP-WSH FUSE FRONT WASHER SWITCH FRONT WIPER MOTOR (AT LEFT REAR OF ENGINE COMPT) FRONT WIPER SWITCH FUSE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE HOT IN ON OR ACC HOT IN ON OR START J/B 3 (BEHIND RIGHT SIDE OF DASH) JUNCTION JUNCTION CONNECTOR 16 (RIGHT SIDE OF DASH) JUNCTION CONNECTOR 19 (RIGHT SIDE OF DASH) JUNCTION CONNECTOR 24 (IN CENTER CONSOLE) NL PL RB OFF PARK/NEUTRAL POSITION SWITCH (ON RIGHT SIDE OF TRANSMISSION) RED/BLU WIRE RED/WHT WIRE WASHER MOTOR (AT RIGHT FRONT OF ENGINE COMPT, ON WASHER FLUID RESERVOIR) WHT WIRE WHT/BLK WIRE

1 2 3 4 5 6 7 8 9 10 SIS +2 1 2 3 SIG MPX ES 10 11 14 16 4 SIG BECU SPD 2 17 PKB BLK WIRE BLK/ WHT WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BODY ECU (BEHIND LEFT END OF DASH) BRN WIRE COMBINATION DAC RELAY DOME FUSE DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) EB (ON LEFT FRONT INNER FENDER) ECU-B FUSE ECU-IG FUSE EG (ON REAR OF LEFT CYLINDER HEAD) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT) GAUGE FUSE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN ON OR START J/B 1 (BEHIND J/B 2 (BEHIND J/B 2 (BEHIND CENTER OF DASH) JUNCTION CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT) JUNCTION CONNECTOR 11 JUNCTION CONNECTOR 11 (LEFT END OF DASH) JUNCTION CONNECTOR 19 (RIGHT SIDE OF DASH) JUNCTION CONNECTOR 20 (RIGHT SIDE OF DASH) JUNCTION CONNECTOR 23 (LOWER RIGHT SIDE OF DASH) JUNCTION CONNECTOR 7, 8 (LEFT END OF DASH) JUNCTION CONNECTOR 9 (LEFT END OF DASH) LT GRN WIRE METER PARKING BRAKE SWITCH (AT BASE OF BRAKE LEVER ASSEMBLY) PNK/BLU WIRE RAIN SENSOR (AT TOP CENTER OF FRONT WINDSHIELD) RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SHT SIM WSHI WSLO WSE SPEEDO- METER STOP FUSE STOP LIGHT SWITCH VIO/RED WIRE WASH WSAU +B EVR STP WASHER IND WASHER LEVEL SENSOR (AT RIGHT FRONT OF ENGINE COMPT, ON WASHER FLUID RESERVOIR) WHT/BLK WIRE WHT/RED WIRE WIG WIPER RELAY (BEHIND RIGHT SIDE OF DASH) YEL/RED WIRE
