Headlights circuit for Lexus GX J120 (2002-2009)

10 22 18 SIG AUTOMATIC LIGHT CONTROL SENSOR (ON UPPER LEFT SIDE OF DASH) BLU/WHT WIRE BODY ECU CLTB CLTE CLTS CLTS CLTB COMBINATION SWITCH DCTY DIMMER SWITCH DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) DRL ECU-IG FUSE FUSE GENERATOR GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE HEAD HEAD TAIL AUTO HEAD TAIL OFF AUTO FOG LIGHT SWITCH HEAD TAIL OFF AUTO OFF HIGH LOW FLASH HOT IN ON OR ACC HOT IN ON OR START JUNCTION LEFT FRONT DOOR COURTESY SWITCH (LOWER LEFT "B" PILLAR) LEFT REAR DOOR COURTESY SWITCH (BOTTOM OF LEFT "C" PILLAR) LIGHT CONTROL SWITCH LT GRN WIRE LT GRN/BLK WIRE PARKING BRAKE SWITCH (AT BASE OF BRAKE LEVER ASSEMBLY) PCTY PNK/BLK WIRE PNK/BLU WIRE RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR COURTESY SWITCH (BOTTOM OF RIGHT "B" PILLAR) RIGHT REAR DOOR COURTESY SWITCH (BOTTOM OF RIGHT "C" PILLAR) RLCY RRCY TAIL TAIL RELAY TURN SIGNAL FLASHER (LEFT END OF DASH) UNLOCK WARNING SWITCH WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE

BACK DOOR COURTESY SWITCH (AT LEFT REAR OF VEHICLE, BELOW TAILLIGHT) BLU WIRE BLU/WHT WIRE BRN WIRE COMBINATION METER EA (ON RIGHT FRONT INNER FENDER) EB (ON LEFT FRONT INNER FENDER) ECU-B FUSE EG (ON REAR OF LEFT CYLINDER HEAD) ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPARTMENT) FR FOG FUSE FR FOG RELAY GRN/RED WIRE HEAD LEFT LOW HEAD FUSE RELAY HIGH BEAM IND HOT AT ALL TIMES J/B 2 (BEHIND CENTER OF DASH) J/B FUSE JUNCTION JUNCTION CONNECTOR LEFT FRONT FOG LIGHT LEFT HIGH HEAD FUSE LEFT HIGH HEADLIGHT LEFT LOW HEADLIGHT LT GRN WIRE LT GRN/RED WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT FOG LIGHT RIGHT HIGH HEAD FUSE RIGHT HIGH HEADLIGHT RIGHT LOW HEAD FUSE RIGHT LOW HEADLIGHT WHT WIRE WHT/BLK WIRE WHT/RED WIRE
