Lexus GX J120 (2002-2009) w/ lexus navigation system w/o lexus navigation system Wiring diagram
This page shows the only wiring diagram for the component.w/ lexus navigation system w/o lexus navigation system, which is found in the car Lexus GX J120 (2002-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ lexus navigation system w/o lexus navigation system (1 of 1)
A/C ECU A/C CONTROL ASSEMBLY (BEHIND RIGHT SIDE OF DASH)
ALT FUSE
BLK WIRE
BLU WIRE
DEFOG FUSE
DEFOG RELAY
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH)
EB (ON LEFT FRONT INNER FENDER)
ENGINE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
ENGINE ROOM R/B (ON LEFT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
GRY/BLU WIRE
HEATER CONTROL SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
JUNCTION CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT)
JUNCTION CONNECTOR 15 (RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 2, 3 (LEFT SIDE OF ENGINE COMPT)
L-RDEF
REAR WINDOW DEFOGGER
RED WIRE
RRDEF
S-RDEF
S-RDEF L-RDEF
W/ LEXUS NAVIGATION SYSTEM
W/ LEXUS NAVIGATION SYSTEM W/O LEXUS NAVIGATION SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Rear defogger circuit -> W/ LEXUS NAVIGATION SYSTEM W/O LEXUS NAVIGATION SYSTEM
