Lexus GX J120 (2002-2009) vcc up gnd sgnd Wiring diagram
This page shows the only wiring diagram for the component.vcc up gnd sgnd, which is found in the car Lexus GX J120 (2002-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vcc up gnd sgnd (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 DN RX
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BODY ECU
BRN/BLK WIRE
D RR P/W FUSE
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH) P FR P/W FUSE
ECU-IG FUSE
FUSE
GRN WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ACC OR ON
HOT IN ON OR START
J/C 11 (LEFT END OF DASH)
J/C 17 (RIGHT SIDE OF DASH)
J/C 23 (LOWER RIGHT SIDE OF DASH)
J/C 28 (AT RIGHT KICK PANEL)
KOF BDR
LEFT REAR POWER WINDOW CONTROL SWITCH
LEFT REAR POWER WINDOW MOTOR (IN LEFT REAR DOOR)
P RR P/W FUSE
PLS SSRB
RIGHT FRONT POWER WINDOW CONTROL SWITCH
RIGHT FRONT POWER WINDOW MOTOR (IN RIGHT FRONT DOOR)
RIGHT REAR POWER WINDOW CONTROL SWITCH
RIGHT REAR POWER WINDOW MOTOR (IN RIGHT REAR DOOR)
SIG
SSRB PLS
VCC UP GND SGND
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Power windows circuit (2 of 2) -> VCC UP GND SGND
