Lexus GX J120 (2002-2009) tsr tsl Wiring diagrams
This page contains all the electrical diagrams for the component. tsr tsl, in which he is found in the car Lexus GX J120 (2002-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
tsr tsl wiring diagram (1 of 2)
A/C AMBIENT TEMPERATURE SENSOR (BEHIND CENTER OF FRONT GRILLE)
A/C SOLAR SENSOR (ON UPPER LEFT SIDE OF DASH)
ACCESSORY METER
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR LINEAR CONTROLLER (BEHIND LOWER RIGHT CENTER OF DASH)
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/YEL WIRE
DATA SG TH+
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH)
ENGINE COMPT)
FUSE
GATEWAY ECU (BEHIND CENTER OF DASH)
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
GTX+ GTX-
HOT IN ON OR START
J/B 1 (BEHIND CENTER OF DASH)
J/B 2 (BEHIND CENTER OF DASH)
JUNCTION CONNECTOR 1 (LEFT SIDE OF
JUNCTION CONNECTOR 19 (RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 23 (LOWER RIGHT SIDE OF DASH) IL
JUNCTION CONNECTOR 9 (LEFT END
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
MULTI-DISPLAY
OF DASH)
OF ENGINE COMPT) PNK 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 WIRE
ORG/ WIRE
PNK 11 12 13 14 15 16 17 18 19 20 22 23 24 25 WIRE
PNK/BLK WIRE
PNK/GRN WIRE
PRESSURE
PRESSURE SWITCH (ON RIGHT FRONT OF ENGINE COMPT)
RED WIRE
SWITCH
TSR TSL
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
VM +B SI GND
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Front a/c circuit, with navigation (2 of 4) -> TSR TSL
tsr tsl wiring diagram (2 of 2)
A/C AMBIENT TEMPERATURE SENSOR (BEHIND CENTER OF FRONT GRILLE)
A/C SOLAR SENSOR (ON UPPER LEFT SIDE OF DASH)
ACCESSORY METER
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR LINEAR CONTROLLER (BEHIND LOWER RIGHT CENTER OF DASH)
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/YEL WIRE
DATA SG TH+
DRIVER SIDE J/B (BEHIND LOWER LEFT END OF DASH)
FUSE
GRN WIRE
GRN/ORG WIRE
GRY WIRE
GRY/BLU WIRE
HOT IN ON OR START
J/B 1 (BEHIND CENTER OF DASH)
J/B 2 (BEHIND CENTER OF DASH)
JUNCTION CONNECTOR 1 (LEFT SIDE OF ENGINE COMPT)
JUNCTION CONNECTOR 19 (RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 23 (LOWER RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 9 (LEFT END OF DASH)
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
OF ENGINE COMPT) PNK 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 WIRE
ORG/ WIRE
PNK 10 11 12 13 14 15 16 17 18 19 20 21 22 WIRE
PNK/BLK WIRE
PNK/GRN WIRE
PRESSURE
PRESSURE SWITCH (ON RIGHT FRONT OF ENGINE COMPT)
RED WIRE
SWITCH
TSR TSL
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
VM +B SI GND
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Front a/c circuit, without navigation (2 of 4) -> TSR TSL
